Videos & documents
Documents
100DSP
SKU: 100DSP
MPN: 100DSP
Key specs
View all- Material
- Die Cast Zinc, Spring Steel, Polycarbonate Bushing
- Size
- 3/8 IN
- Type
- Double Snap Lock 90 DEG BX Connector
Description
Product overview
3/8" 90� Double Snap Lock BX Connector
3/8" 90� Double Snap Lock BX Connector
Manufacturer highlights
Topaz's line of economical and efficient Snap Lock Connectors enable fast, two step tool free installations of metal clad or armored cable to steel bo...
Topaz's line of economical and efficient Snap Lock Connectors enable fast, two step tool free installations of metal clad or armored cable to steel boxes or enclosures. Featuring a pre-assembled and secure anti-short bushing; fabricated from corrosion resistant and durable zinc die cast; the 90' BX connector is ideal for tight spaces and is easily removed without tools. 3/8' and 1/2' sizes will fit 1/2' knockout; polycarbonate bushing; UL listed.
- Provides significant labor savings when installing metal clad or armored cable to steel boxes or enclosures
- No tools are required when assembling to the cable or box
- The anti-short bushing is pre-assembled and will not fall out during transit or installation
- The double snap lock BX connector can easily be removed without tools
Additional manufacturer notes
- Short name
- TPZ
- Feed description
- TPZ 100DSP 3/8"ASQ DOUBLE SNAP 90 D
- Invoice description
- 3/8"ASQ DOUBLE SNAP 90 DEG.INS 25/250-PK
Specifications
- UPC
- 751338871236
- UNSPSC
- 39121419
- Country of Origin
- MUL
- Material
- Die Cast Zinc, Spring Steel, Polycarbonate Bushing
- Size
- 3/8 IN
- Type
- Double Snap Lock 90 DEG BX Connector
- Connection
- Double Snap Lock
- Connectors (IN)
- Double Snap Lock IN
- Diameter
- 0.972 IN
- For Use With
- Fits 1/2 IN Knockout, AL and Steel 3/8 IN RWFMC, AL and Steel AC 14-2 to 10-3, AL and Steel MC/MCI-A/HCF 14-2 to 10-4
- Height
- 1.36 IN
- Label Description
- BX CONNECTOR-DOUBLE SNAP LOCK
- Length
- 1.72 IN
- Material
- Die Cast Zinc, Spring Steel, Polycarbonate Bushing
- Size
- 3/8 IN
- Size (IN)
- 3/8" IN
- Size (trade) (IN)
- 3/8" IN
- Standard
- UL File Number E148716
- Type
- Double Snap Lock 90 DEG BX Connector
- Manufacturer keywords
- 3/8"ASQ DOUBLE SNAP 90 DEG.INS
