$245.52 / EA
In stock (0)
Lead time: over 7 days
may be longer on small orders
Scotch® Tape 130C is a linerless 30 mil thick, premium grade, rubber splicing tape used for splicing and terminating cables and wires. It withstands temperatures up to 194 °F (90 °C) with emergency overload up to 266 °F (130 °C). The tape has excellent electrical and mechanical properties to provide moisture seal protection.
Scotch® Tape 130C is a linerless 30 mil thick, premium grade, rubber splicing tape used for splicing and terminating cables and wires. It withstands temperatures up to 194 °F (90 °C) with emergency overload up to 266 °F (130 °C). The tape has excellent electrical and mechanical properties to provide moisture seal protection.
Add primary electrical insulation to solid, dielectric insulated cables with a 69 kV rating by using...150
Add primary electrical insulation to solid, dielectric insulated cables with a 69 kV rating by using Scotch® Tape 130C. Its self-fusing, linerless, ethylene propylene backing paired with a tough, rubber-resin adhesive offers electrical protection and mechanical padding. The impressive conformability of this tape provides void-free buildups and a reliable moisture seal from its excellent mechanical and electrical properties. Scotch® Tape 130C is intended for use on cable primary insulation repair applications, low- and high-voltage bus bar insulation and end-sealing cables. This product is ASTM Approved and RoHS 2011/65/EU Compliant.
- Highly conformable, rubber-resin adhesive and the self-fusing, ethylene propylene, rubber backing provides UV resistance
- Provides an excellent thermal dissipation of splice heat
- Excellent electrical and mechanical properties offer a moisture seal and void-free buildups
- Withstands temperatures up to 194 °F (90 °C)
- Highly conformable, rubber-resin adhesive and the self-fusing, ethylene propylene, rubber backing provides UV resistance
- Provides an excellent thermal dissipation of splice heat
- Excellent electrical and mechanical properties offer a moisture seal and void-free buildups
- Withstands temperatures up to 194 °F (90 °C)
- UPC
- 054007417521
- UNSPSC
- 31201534
- Country of Origin
- USA
60220
$5.21 /ea
Rubber Splicing Tape 600V 3/4” x 22 Ft x 30 Mil - Our 600 Volt Max Splicing Tape is used for insulating Splices and Terminations in Electrical Applications.Rubber Splicing Tape 600V 3/4” x 22 Ft x 30 Mil features include: 600 Volt Max Rubber Splicing Tape is Self Fusing with Liner High quality unvulcanized rubber that will bond quickly to itself to form a solid mass of water-tight protection for electrical wires Primary insulation for electrical wires and cables splices of not more than 600V Splicing tape is flexible to withstand expansion and contraction High resistance to salt water, steam, oils, detergents, and other chemicals make it an ideal tape for pipe repair, automotive, marine, construction, etc.High elongation conforms to irregular shapesDielectric strength 490 Volts per mil, for use up to 176deg;F (80deg;C) Order Qty of 1 = 1 Piece Below is more info on our Rubber Splicing Tape 600V 3/4” x 22 Ft x 30 Mil
| Attributed Data | Included |
|---|---|
| Color | Black Yes |
| MAXIMUM VOLTAGE | 600 Volts Yes |
| Material | Rubber Yes |
| Product Height | 30 Mil Yes |
| Product Length | 22' Yes |
| Product Width | 3/4" Yes |
| Size | 3/4" x 22' x .030" Yes |
| Tape Type | Rubber Splicing Yes |
60222
$15.24 /ea
Rubber Splicing Tape 600V 2” x 22 Ft x 30 Mil - Our 600 Volt Max Splicing Tape is used for insulating Splices and Terminations in Electrical Applications.Rubber Splicing Tape 600V 2” x 22 Ft x 30 Mil features include: 600 Volt Max Rubber Splicing Tape is Self Fusing with Liner High quality unvulcanized rubber that will bond quickly to itself to form a solid mass of water-tight protection for electrical wires Primary insulation for electrical wires and cables splices of not more than 600V Splicing tape is flexible to withstand expansion and contraction High resistance to salt water, steam, oils, detergents, and other chemicals make it an ideal tape for pipe repair, automotive, marine, construction, etc.High elongation conforms to irregular shapesDielectric strength 490 Volts per mil, for use up to 176deg;F (80deg;C) Order Qty of 1 = 1 Piece Below is more info on our Rubber Splicing Tape 600V 2” x 22 Ft x 30 Mil
| Attributed Data | Included |
|---|---|
| Color | Black Yes |
| MAXIMUM VOLTAGE | 600 Volts Yes |
| Material | Rubber Yes |
| Product Height | 30 Mil Yes |
| Product Length | 22' Yes |
| Product Width | 2" Yes |
| Size | 2" x 22' x .030" Yes |
| Tape Type | Rubber Splicing Yes |
130C-1x30FT-3M
$491.04 /ea
Scotch® Tape 130C is a linerless 30 mil thick, premium grade, rubber splicing tape used for splicing and terminating cables and wires. It withstands temperatures up to 194 °F (90 °C) with emergency overload up to 266 °F (130 °C). The tape has excellent electrical and mechanical properties to provide moisture seal protection.
| Attributed Data | Included |
|---|---|
| Backing Material | Ethlylene Propylene Rubber Yes |
| Color | Black Yes |
| Material | Ethylene Propylene Rubber Yes |
| Size | 1 in x 30 ft Yes |
| Standard | ASTM D-4388 type 1, 2 & 3 HH-I-3825B Yes |
| Sub Brand | Scotch Yes |
| Tensile Strength | 250 Pound-Force Per Square Inch Yes |
| Thickness | 30 Milli-inch (mil) Yes |
| Type | linerless Ethylene Propylene Rubber Yes |
| Product Image |
|
|
|
|---|---|---|---|
|
60220
Rubber Splicing Tape 600V 3/4” x 22 Ft x 30 Mil - Our 600 Volt Max Splicing Tape is used for insulating Splices and Terminations in Electrical Applications.Rubber Splicing Tape 600V 3/4” x 22 Ft x 30 Mil features include: 600 Volt Max Rubber Splicin...
$5.21 / EA
*
* This is the minimum price that we are able to advertise. Call us at
(800) 462-7733
and we will offer a lower price.
|
60222
Rubber Splicing Tape 600V 2” x 22 Ft x 30 Mil - Our 600 Volt Max Splicing Tape is used for insulating Splices and Terminations in Electrical Applications.Rubber Splicing Tape 600V 2” x 22 Ft x 30 Mil features include: 600 Volt Max Rubber Splicing Ta...
$15.24 / EA
*
* This is the minimum price that we are able to advertise. Call us at
(800) 462-7733
and we will offer a lower price.
|
130C-1x30FT-3M
Scotch® Tape 130C is a linerless 30 mil thick, premium grade, rubber splicing tape used for splicing and terminating cables and wires. It withstands temperatures up to 194 °F (90 °C) with emergency overload up to 266 °F (130 °C). The tape has excelle...
$491.04 / EA
|
|
| Attributed Data | |||
| Backing Material | Ethlylene Propylene Rubber Ethlylene Propylene Rubber | ||
| Color | Black Black | ||
| Length | 30 ft 30 ft | ||
| MAXIMUM VOLTAGE | 600 Volts 600 Volts | ||
| Material | Ethylene Propylene Rubber Ethylene Propylene Rubber | Rubber Rubber | |
| Product Height | 30 Mil 30 Mil | ||
| Product Length | 22' 22' | ||
| Product Width | 2" 2" | 3/4" 3/4" | |
| Size | 1 in x 30 ft 1 in x 30 ft | 2" x 22' x .030" 2" x 22' x .030" | 3/4" x 22' x .030" 3/4" x 22' x .030" |
| Standard | ASTM D-4388 type 1, 2 & 3 HH-I-3825B ASTM D-4388 type 1, 2 & 3 HH-I-3825B | ||
| Sub Brand | Scotch Scotch | ||
| Tape Type | Rubber Splicing Rubber Splicing | ||
| Temperature Range | 0 to 194 F 0 to 194 F | ||
| Tensile Strength | 250 Pound-Force Per Square Inch 250 Pound-Force Per Square Inch | ||
| Thickness | 30 Milli-inch (mil) 30 Milli-inch (mil) | ||
| Type | linerless Ethylene Propylene Rubber linerless Ethylene Propylene Rubber | ||
| Width | 1 in 1 in | ||
| Add a product to the cart | Show more details | Show more details | Show more details |
