$21.14 / EA
manufacturer discounts
learn about discounts
- $18.23 for $1,300.00+
- $17.20 for $2,000.00+
- $16.33 for $3,000.00+
Local stock: 0
Lead time:
1
-
2
working days
20 Amp, 125 Volt, NEMA 5-20R, 2P, 3W, Decora Plus Duplex Receptacle, Straight Blade, Hospital Grade, Self Grounding, , Back & Side Wired, Steel Strap, - Ivory
20 Amp, 125 Volt, NEMA 5-20R, 2P, 3W, Decora Plus Duplex Receptacle, Straight Blade, Hospital Grade, Self Grounding, , Back & Side Wired, Steel Strap, - Ivory
150
- UPC
- 078477818763
- UNSPSC
- 39121406
- Country of Origin
- MX
- Amperage Rating:
- 20 A
- Color:
- Ivory
- Material:
- Nylon
- Number Of Poles:
- 2
- Size:
- 46 H x 1.52 W x 1.14 D IN
- Type:
- Straight Blade;Duplex Outlet
- Voltage Rating:
- 125 V
- Amperage Rating:
- 20 A
- Color:
- Ivory
- Connection:
- Back and Side Wired
- Dielectric Strength:
- 2000 (Min.) V
- Environmental Conditions:
- Flammability (Rated V-2 per UL94)
- Material:
- Nylon
- Mounting:
- Wall Box
- NEMA Rating:
- 5-20R
- Number Of Poles:
- 2
- Number Of Wires:
- 3
- Phase:
- 1
- Size:
- 46 H x 1.52 W x 1.14 D IN
- Standard:
- NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File 152105);UL498HG (File E13399)
- Sub Brand:
- Decora Plus
- Temperature Rating:
- -40 to +60 DEG C
- Type:
- Straight Blade;Duplex Outlet
- Voltage Rating:
- 125 V
- Wire Size:
- 14-10 AWG
