1BS102
SKU: 1BS102
MPN: 1BS102
Key specs
View all- Amperage Rating
- 400 A
- Material
- Tin-plated aluminum connectorZinc-plated steel studs/nut/washerMolded black phenolic base
- Size
- 2.25 In Width X 2.53 In Height
- Type
- Accessory
- Voltage Rating
- 600 V
- Wattage
- 150 CEL
Description
Product overview
Eaton Bussmann series 1BS10x Universal fuse block, Modular, 400A, 150 Celsius, 200 kAIC, Molded black phenolic base, Tin-plated aluminum connector, Zinc-plated steel studs/nut/washer, Stud, 600 V, Used with Type SC fuses, #6-250 kcmil Cu/Al
Eaton Bussmann series 1BS10x Universal fuse block, Modular, 400A, 150 Celsius, 200 kAIC, Molded black phenolic base, Tin-plated aluminum connector, Zinc-plated steel studs/nut/washer, Stud, 600 V, Used with Type SC fuses, #6-250 kcmil Cu/Al
Manufacturer highlights
Bussmann series circuit protection products and services focus on downtime reduction, workplace safety and Code compliance for the industrial/MRO, OEM...
Bussmann series circuit protection products and services focus on downtime reduction, workplace safety and Code compliance for the industrial/MRO, OEM and construction markets. From electrical power fuses to fuse blocks and holders and engineering services, the Bussmann brand stands for protection you rely on.
Additional manufacturer notes
- Short name
- BUSS
- Feed description
- BUSS 1BS102 BUSS FUSEBLOCK
- Invoice description
- BUSS FUSEBLOCK
Specifications
- UPC
- 051712134996
- UNSPSC
- 39121624
- Country of Origin
- MX
- Amperage Rating
- 400 A
- Material
- Tin-plated aluminum connectorZinc-plated steel studs/nut/washerMolded black phenolic base
- Size
- 2.25 In Width X 2.53 In Height
- Type
- Accessory
- Voltage Rating
- 600 V
- Wattage
- 150 CEL
- Amperage Rating
- 400 A
- Connection
- Screw
- Dimensions
- 6.6000 IN X 3.2000 IN X 2.5000 IN
- Material
- Tin-plated aluminum connectorZinc-plated steel studs/nut/washerMolded black phenolic base
- Mounting
- Stud
- Operating Temperature
- 150 Deg C
- Size
- 2.25 In Width X 2.53 In Height
- Standard
- Contact factory,RoHS Compliant
- Sub Brand
- Bussmann Series
- Type
- Accessory
- Voltage Rating
- 600 V
- Wattage
- 150 CEL
Do you have a question about 1BS102?
