22360THSS277VAG
SKU: 22360THSS277VAG
MPN: 22360THSS277VAG
Key specs
View all- Type
- Infrared Heater
- Voltage Rating
- 277 VAC
- Wattage
- 4,800 W
Description
Product overview
Electric Infrared Heater, 4.8KW, 277V, Dimensions- 24 Length x 21-1/2 Width x 11 Height IN, 1, 3 PH, Stainless Steel Housing, Mul-T-Mount, BTU Rating- 16382, THSS Series, 60° Symmetric
Electric Infrared Heater, 4.8KW, 277V, Dimensions- 24 Length x 21-1/2 Width x 11 Height IN, 1, 3 PH, Stainless Steel Housing, Mul-T-Mount, BTU Rating- 16382, THSS Series, 60° Symmetric
Manufacturer highlights
Additional manufacturer notes
- Short name
- TPI
- Feed description
- TPI 22360THSS277VAG 3 Lmp 8MM 4.8KW
- Invoice description
- 3 Lmp 8MM 4.8KW 277V 60Sym MTM Htr SS
Specifications
- UPC
- 686334491105
- UNSPSC
- 40101824
- Country of Origin
- US
- Type
- Infrared Heater
- Voltage Rating
- 277 VAC
- Wattage
- 4,800 W
- Coverage
- 10.5 x 10.5 @ 8 FT, 13 x 13 @ 10 FT, 15 x 15 @ 12 FT, 17 x 17 @ 14 FT, 21 x 21 @ 16 FT FT
- Dimensions
- 24 (L) x 21-1/2 (W) x 11 (H) IN
- Heating Capacity
- 16382 BTU
- Housing Material
- Stainless Steel
- Lamp Size
- 8 MM
- Lamp Type
- Quartz Lamp
- Model
- 223-60-THSS-277V-AG
- Mounting
- Mul-T-Mount
- Mounting Hole Spacing
- 23-1/2 IN
- Number of Lamps
- 3
- Phase
- 1, 3
- Reflector Material
- Gold Anodized Aluminum
- Reflector Type
- 60° Symmetric
- Series
- THSS
- Standard
- cETLus Listed
- Type
- Infrared Heater
- Voltage Rating
- 277 VAC
- Wattage
- 4,800 W
- Weight
- 25 LB
