20 Amp, 250 Volt- 3PY, Flush Mounting Locking Receptacle, Industrial Grade, Grounding, V-0-MAX, Black
20 Amp, 250 Volt- 3PY, Flush Mounting Locking Receptacle, Industrial Grade, Grounding, V-0-MAX, Black
20 Amp, 250 Volt- 3PY, Flush Mounting Locking Receptacle, Industrial Grade, Grounding, V-0-MAX, Black

Image colors may not be accurate.
Please see details, or call (800) 462-7733 for more information.

2420

$30.63 / EA

manufacturer discounts
learn about discounts

  • $26.13 for $1,300.00+
  • $24.66 for $2,000.00+
  • $23.41 for $3,000.00+

In stock (0)
Lead time: over 7 days
may be longer on small orders

20 Amp, 250 Volt- 3PY, Flush Mounting Locking Receptacle, Industrial Grade, Grounding, V-0-MAX, Black

20 Amp, 250 Volt- 3PY, Flush Mounting Locking Receptacle, Industrial Grade, Grounding, V-0-MAX, Black

150

UPC
078477809341
UNSPSC
39121406
Country of Origin
MX
Amperage Rating:
20 A
Color:
Black
Material:
PBT
Number Of Poles:
3
Size:
3.63 H x 1.69 W x 1.31 D IN
Type:
Flush Mount Locking Receptacle
Voltage Rating:
250 V
Amperage Rating:
20 A
Color:
Black
Connection:
Back Wired;Side Wired
Dielectric Strength:
2000 (Min.) V
Environmental Conditions:
Flammability (Rated V-2, Rated V-0 per UL94)
Material:
PBT
Mounting:
Box
NEMA Rating:
L15-20R
Number Of Poles:
3
Number Of Wires:
4
Phase:
3
Size:
3.63 H x 1.69 W x 1.31 D IN
Standard:
NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No.42;UL Fed Spec WC-596 (File E13399);UL Listed 498
Sub Brand:
V-0-Max
Temperature Rating:
-40 to +60 DEG C
Type:
Flush Mount Locking Receptacle
Voltage Rating:
250 V
Wire Size:
14-8 AWG
