$36.39 / EA
manufacturer discounts
learn about discounts
- $29.54 for $1,300.00+
- $27.88 for $2,000.00+
- $26.47 for $3,000.00+
20 Amp, 250 Volt 3-phase, NEMA L15-20R, 3P, 4W, Locking Connector, Industrial Grade, Grounding - Black-White
20 Amp, 250 Volt 3-phase, NEMA L15-20R, 3P, 4W, Locking Connector, Industrial Grade, Grounding - Black-White
150
- UPC
- 078477808306
- UNSPSC
- 39121402
- Country of Origin
- US
- Amperage Rating:
- 20 A
- Color:
- Black/White
- Material:
- Super Tough Nylon (Body)
- Number Of Poles:
- 3
- Size:
- 28 Dia x 3.53 H IN
- Type:
- Locking Connector
- Voltage Rating:
- 250 V
- Amperage Rating:
- 20 A
- Assembly Screws:
- Zinc Plated Steel
- Blades/contacts Material:
- Solid Brass
- Color:
- Black/White
- Environmental Conditions:
- Flammability (Rated V-2 per UL94);Operating Temperature Range (-40 to +60 DEG C)
- Horsepower:
- 3 HP
- Material:
- Super Tough Nylon (Body)
- Mounting:
- Cable
- NEMA Rating:
- L15-20R
- Number Of Poles:
- 3
- Number Of Wires:
- 4
- Phase:
- 3
- Replacement Parts Material:
- Thermoplastic (Back Cover);Nylon (Wire Module, Cord-Clamp, Clamp Insert);Brass (Terminal Screws)
- Size:
- 28 Dia x 3.53 H IN
- Standard:
- NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA Certified (File LR-406);UL Fed Spec WC-596 (File E13393);UL Listed 498 (File E13393)
- Sub Brand:
- Black & White
- Type:
- Locking Connector
- Voltage Rating:
- 250 V
- Wire Size:
- 18-10 AWG (Terminal Accommodation); .560-.775 IN (Cord Grip Range)
