$41.09 / EA
manufacturer discounts
learn about discounts
- $35.43 for $1,300.00+
- $33.44 for $2,000.00+
- $31.74 for $3,000.00+
Local stock: 0
Lead time:
1
-
2
working days
30 Amp, 120/208 Volt 3PY, NEMA L21-30R, 4P, 5W, Locking Connector, Industrial Grade, Grounding - Black-White
30 Amp, 120/208 Volt 3PY, NEMA L21-30R, 4P, 5W, Locking Connector, Industrial Grade, Grounding - Black-White
150
- UPC
- 078477808603
- UNSPSC
- 39121402
- Country of Origin
- US
- Amperage Rating:
- 30 A
- Color:
- Black/White
- Material:
- Impact Modified Nylon
- Number Of Poles:
- 4
- Size:
- 2.22 Diameter X 3.78 L IN
- Type:
- Locking Connector
- Voltage Rating:
- 120/208 V
- Amperage Rating:
- 30 A
- Color:
- Black/White
- Connection:
- Screw Terminal
- Cord Type:
- S;SO;ST;STO;STW;STW-A;STOW-A;SOO;STOO
- Environmental Conditions:
- Flammability (Rated V-2 per UL 94);Operating Temperature Range (-40 to +60 DEG C)
- Horsepower:
- 3 HP
- Material:
- Impact Modified Nylon
- Mounting:
- Cable
- NEMA Rating:
- L21-30R
- Number Of Poles:
- 4
- Number Of Wires:
- 5
- Phase:
- 3
- Size:
- 2.22 Diameter X 3.78 L IN
- Standard:
- NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA Certified (File LR-406);UL Fed Spec WC-596 (File E13393);UL498 (File E13393)
- Sub Brand:
- Black & White
- Type:
- Locking Connector
- Voltage Rating:
- 120/208 V
- Wire Size:
- 18-10 AWG
