$132.75 / EA
manufacturer discounts
learn about discounts
- $114.44 for $1,300.00+
- $108.03 for $2,000.00+
- $102.54 for $3,000.00+
Local stock: 0
Lead time:
1
-
2
working days
30-Amp, 125-Volt, Industrial Grade, Locking Connector, Grounding, Wetguard, Black
30-Amp, 125-Volt, Industrial Grade, Locking Connector, Grounding, Wetguard, Black
150
- UPC
- 078477014684
- UNSPSC
- 39121402
- Country of Origin
- US
- Amperage Rating:
- 30 A
- Color:
- Black
- Material:
- TPV
- Number Of Poles:
- 2
- Size:
- 2.75 Diameter X 5.52 L IN
- Type:
- Watertight Connector;Locking
- Voltage Rating:
- 125 V
- Amperage Rating:
- 30 A
- Color:
- Black
- Connection:
- Screw Terminal
- Cord Type:
- SO;ST;STO;SOO
- Environmental Conditions:
- Flammability (Rated V-2 per UL 94 (Wiring Module));Operating Temperature Range (-40 to +60 DEG C)
- Material:
- TPV
- Mounting:
- Cable
- NEMA Rating:
- L5-30R
- Number Of Poles:
- 2
- Number Of Wires:
- 3
- Phase:
- 1
- Size:
- 2.75 Diameter X 5.52 L IN
- Standard:
- NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA (C22.2 No.42);UL (498)
- Sub Brand:
- Wetguard
- Type:
- Watertight Connector;Locking
- Voltage Rating:
- 125 V
- Wire Size:
- 12-8 AWG
Recently Viewed
-
29W47-B
LEVITON MANUFACTURING
30-Amp, 125-Volt, Industrial Grade, Locking Connector, Grounding, Wetguard, Black
See more details -
80-2590
SATCO PRODUCTS
Unfortunately, we do not have a description available for 80-2590. Please call (800) 462-7733...
See more details -
CLM0C08120
SIEMENS INDUSTRY, INC.
Mechanically held lighting contactor, H2 0 N.C. / 8 N.O. poles, 110VAC 50HZ/120VAC 60HZ coil, Non-combination type, Enclosure NEMA type (open), No enc...
