$1,164.16 / EA *
* This is the minimum price that we are able to advertise. Call us at (800) 462-7733 and we will offer a lower price.
manufacturer discounts
learn about discounts
- $1,020.82 for $1,500.00+
- $978.99 for $2,500.00+
- $937.15 for $4,000.00+
In stock (0)
Lead time: over 7 days
may be longer on small orders
Electric Infrared Heater, 5KW, 480V, Dimensions- 33 Length x 15 Width x 11 Height IN, 1 PH, Aluminum Housing, Mul-T-Mount, BTU Rating- 17065, THA Series, 30° Symmetric
Electric Infrared Heater, 5KW, 480V, Dimensions- 33 Length x 15 Width x 11 Height IN, 1 PH, Aluminum Housing, Mul-T-Mount, BTU Rating- 17065, THA Series, 30° Symmetric
150
- UPC
- 686334489447
- UNSPSC
- 40101824
- Country of Origin
- US
- Type:
- Infrared Heater
- Voltage Rating:
- 480 VAC
- Wattage:
- 5,000 W
- Coverage:
- 6 x 4 @ 8 FT, 7.5 x 5.5 @ 10 FT, 8.5 x 6.5 @ 12 FT, 9.5 x 7.5 @ 14 FT, 10.5 x 8.5 @ 16 FT, 11.5 x 9.5 @ 18 FT, 12.5 x 10.5 @ 20 FT FT
- Dimensions:
- 33 (L) x 15 (W) x 11 (H) IN
- Heating Capacity:
- 17065 BTU
- Housing Material:
- Aluminum
- Lamp Size:
- 8 MM
- Lamp Type:
- Quartz Lamp
- Model:
- 342-30-THA-480V
- Mounting:
- Mul-T-Mount
- Mounting Hole Spacing:
- 32-1/2 IN
- Number of Lamps:
- 2
- Phase:
- 1
- Reflector Material:
- Gold Anodized Aluminum
- Reflector Type:
- 30° Symmetric
- Series:
- THA
- Standard:
- cETLus Listed
- Type:
- Infrared Heater
- Voltage Rating:
- 480 VAC
- Wattage:
- 5,000 W
- Weight:
- 25 LB
22360THA208V
$1,388.80 /ea
Electric Infrared Heater, 4.8KW, 208V, Dimensions- 24 Length x 21-1/2 Width x 11 Height IN, 1, 3 PH, Aluminum Housing, Mul-T-Mount, BTU Rating- 16382, THA Series, 60° Symmetric
| Attributed Data | Included |
|---|---|
| Housing Material | Aluminum Yes |
| Lamp Type | Quartz Lamp Yes |
| Model | 223-60-THA-208V Yes |
| Mounting | Mul-T-Mount Yes |
| Number of Lamps | 3 Yes |
| Phase | 1, 3 Yes |
| Reflector Material | Gold Anodized Aluminum Yes |
| Reflector Type | 60° Symmetric Yes |
| Series | THA Yes |
| Standard | cETLus Listed Yes |
| Type | Infrared Heater Yes |
222A60THSS240VAG
$881.92 /ea
Electric Infrared Heater, 3.2KW, 240V, Dimensions- 24 Length x 15 Width x 11 Height IN, 1 PH, Stainless Steel Housing, Mul-T-Mount, BTU Rating- 10922, THSS Series, 60° Asymmetric
| Attributed Data | Included |
|---|---|
| Housing Material | Stainless Steel Yes |
| Lamp Type | Quartz Lamp Yes |
| Model | 222-A60-THSS-240V-AG Yes |
| Mounting | Mul-T-Mount Yes |
| Number of Lamps | 2 Yes |
| Phase | 1 Yes |
| Reflector Material | Gold Anodized Aluminum Yes |
| Reflector Type | 60° Asymmetric Yes |
| Series | THSS Yes |
| Standard | cETLus Listed Yes |
| Type | Infrared Heater Yes |
22390TH240VAG
$1,200.64 /ea
Electric Infrared Heater, 4.8KW, 240V, Dimensions- 24 Length x 21-1/2 Width x 11 Height IN, 1, 3 PH, Galvanized Steel Housing, Mul-T-Mount, BTU Rating- 16382, TH Series, 90° Symmetric
| Attributed Data | Included |
|---|---|
| Housing Material | Galvanized Steel Yes |
| Lamp Type | Quartz Lamp Yes |
| Model | 223-90-TH-240V-AG Yes |
| Mounting | Mul-T-Mount Yes |
| Number of Lamps | 3 Yes |
| Phase | 1, 3 Yes |
| Reflector Material | Gold Anodized Aluminum Yes |
| Reflector Type | 90° Symmetric Yes |
| Series | TH Yes |
| Standard | cETLus Listed Yes |
| Type | Infrared Heater Yes |
| Product Image |
|
|
|
|---|---|---|---|
|
22360THA208V
Electric Infrared Heater, 4.8KW, 208V, Dimensions- 24 Length x 21-1/2 Width x 11 Height IN, 1, 3 PH, Aluminum Housing, Mul-T-Mount, BTU Rating- 16382, THA Series, 60° Symmetric
$1,388.80 / EA
*
* This is the minimum price that we are able to advertise. Call us at
(800) 462-7733
and we will offer a lower price.
|
222A60THSS240VAG
Electric Infrared Heater, 3.2KW, 240V, Dimensions- 24 Length x 15 Width x 11 Height IN, 1 PH, Stainless Steel Housing, Mul-T-Mount, BTU Rating- 10922, THSS Series, 60° Asymmetric
$881.92 / EA
*
* This is the minimum price that we are able to advertise. Call us at
(800) 462-7733
and we will offer a lower price.
|
22390TH240VAG
Electric Infrared Heater, 4.8KW, 240V, Dimensions- 24 Length x 21-1/2 Width x 11 Height IN, 1, 3 PH, Galvanized Steel Housing, Mul-T-Mount, BTU Rating- 16382, TH Series, 90° Symmetric
$1,200.64 / EA
*
* This is the minimum price that we are able to advertise. Call us at
(800) 462-7733
and we will offer a lower price.
|
|
| Attributed Data | |||
| Coverage | 10.5 x 9.5 @ 8 FT, 13 x 12 @ 10 FT, 15 x 14 @ 12 FT, 17 x 16 @ 14 FT FT 10.5 x 9.5 @ 8 FT, 13 x 12 @ 10 FT, 15 x 14 @ 12 FT, 17 x 16 @ 14 FT FT | 10.5 x 10.5 @ 8 FT, 13 x 13 @ 10 FT, 15 x 15 @ 12 FT, 17 x 17 @ 14 FT, 21 x 21 @ 16 FT FT 10.5 x 10.5 @ 8 FT, 13 x 13 @ 10 FT, 15 x 15 @ 12 FT, 17 x 17 @ 14 FT, 21 x 21 @ 16 FT FT | 17 x 17 @ 8 FT, 21 x 21 @ 10 FT FT 17 x 17 @ 8 FT, 21 x 21 @ 10 FT FT |
| Dimensions | 24 (L) x 15 (W) x 11 (H) IN 24 (L) x 15 (W) x 11 (H) IN | 24 (L) x 21-1/2 (W) x 11 (H) IN 24 (L) x 21-1/2 (W) x 11 (H) IN | |
| Heating Capacity | 10922 BTU 10922 BTU | 16382 BTU 16382 BTU | |
| Housing Material | Aluminum Aluminum | Galvanized Steel Galvanized Steel | Stainless Steel Stainless Steel |
| Lamp Size | 8 MM 8 MM | ||
| Lamp Type | Quartz Lamp Quartz Lamp | ||
| Model | 222-A60-THSS-240V-AG 222-A60-THSS-240V-AG | 223-60-THA-208V 223-60-THA-208V | 223-90-TH-240V-AG 223-90-TH-240V-AG |
| Mounting | Mul-T-Mount Mul-T-Mount | ||
| Mounting Hole Spacing | 23-1/2 IN 23-1/2 IN | ||
| Number of Lamps | 2 2 | 3 3 | |
| Phase | 1 1 | 1, 3 1, 3 | |
| Reflector Material | Gold Anodized Aluminum Gold Anodized Aluminum | ||
| Reflector Type | 60° Asymmetric 60° Asymmetric | 60° Symmetric 60° Symmetric | 90° Symmetric 90° Symmetric |
| Series | TH TH | THA THA | THSS THSS |
| Standard | cETLus Listed cETLus Listed | ||
| Type | Infrared Heater Infrared Heater | ||
| Voltage Rating | 208 VAC 208 VAC | 240 VAC 240 VAC | |
| Wattage | 3.2 kW 3.2 kW | 4,800 W 4,800 W | |
| Weight | 20 LB 20 LB | 25 LB 25 LB | |
| Add a product to the cart | Show more details | Show more details | Show more details |
