$32.70 / EA
manufacturer discounts
learn about discounts
- $29.32 for $1,500.00+
- $28.19 for $2,500.00+
- $27.06 for $3,500.00+
Local stock: 0
Lead time:
over 7 working days
CYL FUSE,FRENCH STD,500V,40A,10 PACK SIZE 22X58MM, 500V 40A WITHOUT INDICATOR ACC. TO FRENCH STANDARD (NFC) CYLINDRICAL FUSE A.M.
CYL FUSE,FRENCH STD,500V,40A,10 PACK SIZE 22X58MM, 500V 40A WITHOUT INDICATOR ACC. TO FRENCH STANDARD (NFC) CYLINDRICAL FUSE A.M.
150
- UPC
- 754554845487
- UNSPSC
- 39121626
- Country of Origin
- DE
- Amperage Rating:
- 40 A
- Material:
- Ceramic/Plastic
- Size:
- NH2
- Type:
- Cylindrical Fuse System
- Voltage Rating:
- 500 V
- Amperage Rating:
- 40 A
- Current / at AC / rated value:
- 40
- Material:
- Ceramic/Plastic
- Measurable line frequency / Full-scale value:
- 45
- Measurable line frequency / initial value:
- 62
- Net weight:
- 49.0g
- Operating class of the fuse link:
- aM
- Operating current / Rated value:
- 40
- Operating voltage / rated value:
- 690
- Power loss [W] / for rated value of the current / at AC / in hot operating state / per pole:
- 3.2
- Power loss [W] / maximum:
- 3.2
- Product component / striker:
- No
- Product designation:
- Cylindricalfuselink
- Reference code / acc. to DIN EN 61346-2:
- F
- Reference code / acc. to DIN EN 81346-2:
- F
- Size:
- NH2
- Size of the fuse link:
- 22x58mm
- Standard:
- NFC
- Sub Brand:
- SENTRON
- Supply voltage / at DC:
- 250
- Supply voltage / rated value / maximum:
- 690V
- Supply voltage / rated value / minimum:
- 10V
- Switching capacity short-circuit current:
- 120kA
- Tripping characteristic class:
- aM
- Type:
- Cylindrical Fuse System
- Type of voltage:
- AC
- Voltage Rating:
- 500 V
- mounting position:
- Any,preferablyvertical
- product brand name:
- SENTRON
