3RE41225AA514AY0
SKU: 3RE41225AA514AY0
MPN: 3RE41225AA514AY0
Description
Product overview
Non-reversing motor starter, Frame size 0, Three phase full voltage, UL horsepower rating Hp@VAC, 5@208, 5@230, 10@460, 15@575, Bimetal overload relay, Fixed Trip Class 10, OLR amp range 11 - 16, 220/240 V AC 50/60HZ coil, Non-combination type, Enclosure NEMA type 1, Indoor general purpose use, Standard width enclosure, Standards UL 60947-4-1, Certifications cULus
Non-reversing motor starter, Frame size 0, Three phase full voltage, UL horsepower rating Hp@VAC, 5@208, 5@230, 10@460, 15@575, Bimetal overload relay, Fixed Trip Class 10, OLR amp range 11 - 16, 220/240 V AC 50/60HZ coil, Non-combination type, Enclosure NEMA type 1, Indoor general purpose use, Standard width enclosure, Standards UL 60947-4-1, Certifications cULus
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A 3RE41225AA514AY0 STARTER,FVNR,S
- Invoice description
- STARTER,FVNR,S0,3PH,THOLR,240VAC,NEMA 1
Specifications
- UPC
- 195125137776
