3RK1105-1BE04-4CA0
SKU: 3RK1105-1BE04-4CA0
MPN: 3RK1105-1BE04-4CA0
Key specs
View all- Type
- 2enablingcircuits
Description
Product overview
ASISAFE ENHANCED SAFETY MONITOR 2 F-RO WITH INTEGRATED SAFETY SLAVE, 2 ENABLINGCIRCUITS INCLUDING CONTROL OF ONE SAFE AS-I OUTPUT / SAFE COUPLING, IP20, WITH SCREW-TYPE TERMINALS (REMOVABLE), SAFE OUTPUT RELAY RESPONSE TIME MAX. 40 MS, MONITOR TYPE 6, VERSION 3, APPLICABLE UP TO CATEGORY 4 (EN 954-1), UP TO PL E (EN ISO 13849-1), UP TO SIL 3 (IEC 61508), FOR AS-INTERFACE / AS-I SAFETY AT WORK
ASISAFE ENHANCED SAFETY MONITOR 2 F-RO WITH INTEGRATED SAFETY SLAVE, 2 ENABLINGCIRCUITS INCLUDING CONTROL OF ONE SAFE AS-I OUTPUT / SAFE COUPLING, IP20, WITH SCREW-TYPE TERMINALS (REMOVABLE), SAFE OUTPUT RELAY RESPONSE TIME MAX. 40 MS, MONITOR TYPE 6, VERSION 3, APPLICABLE UP TO CATEGORY 4 (EN 954-1), UP TO PL E (EN ISO 13849-1), UP TO SIL 3 (IEC 61508), FOR AS-INTERFACE / AS-I SAFETY AT WORK
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A 3RK1105-1BE04-4CA0 AS-I SAFE.MO
- Invoice description
- AS-I SAFE.MON. ENH.+SL, 2 RO,SCREW, 40MS
Specifications
- UPC
- 754554962825
- UNSPSC
- 39121521
- Country of Origin
- CZ
- Type
- 2enablingcircuits
- Ambient temperature / during operation / maximum
- 60 °C
- Ambient temperature / during operation / minimum
- -20 °C
- Ambient temperature / during storage / maximum
- 70 °C
- Rated operational current Ie / AC-12, 50/60 Hz / 250 V
- 3 A
- Rated operational current Ie / AC-15, 50/60 Hz / 115 V
- 3 A
- Rated operational current Ie / AC-15, 50/60 Hz / 230 V
- 3 A
- Rated operational current Ie / DC-12 (DC-1) / 24 V
- 3 A
- Rated operational current Ie / DC-13 (DC-11) / 115 V
- 0.1 A
- Rated operational current Ie / DC-13 (DC-11) / 230 V
- 0.05 A
- Rated operational current Ie / DC-13 (DC-11) / 24 V
- 1 A
- Type
- 2enablingcircuits
