3RK1400-1CE01-0AA2
SKU: 3RK1400-1CE01-0AA2
MPN: 3RK1400-1CE01-0AA2
Key specs
View all- Type
- 4inputs/4outputs
Description
Product overview
MODULE WIDTH 45 MM SCREW-TYPE TERMINAL CONNECT. 4 X 1 OUTPUT, 2A, DC 24V 4 X 1 INPUT, 200MA, PNP DIGITAL, 4I/4O, 2/3-WIRE, IP20 AS-INTERFACE SLIMLINE MOD. S45,
MODULE WIDTH 45 MM SCREW-TYPE TERMINAL CONNECT. 4 X 1 OUTPUT, 2A, DC 24V 4 X 1 INPUT, 200MA, PNP DIGITAL, 4I/4O, 2/3-WIRE, IP20 AS-INTERFACE SLIMLINE MOD. S45,
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A 3RK1400-1CE01-0AA2 AS-I SLIM MO
- Invoice description
- AS-I SLIM MOD,4I/4O,200MA,3-WIRE PNP,2A
Specifications
- UPC
- 754554431208
- UNSPSC
- 32151705
- Country of Origin
- DE
- Type
- 4inputs/4outputs
- AS interface / total current input / max
- 270 mA
- Height
- 106 mm
- I/O configuration
- 7
- Outputs / external power supply 24 V DC
- usingterminals:Terminal13=L+,Terminal19=M
- Outputs / induction protection
- built-in
- Outputs / short-ciruit protection
- built-in
- Outputs / watchdog
- built-in
- Status display / AS-Interface
- greenLED
- Status display / FAULT
- redLED
- Status display / display of I/Os
- yellowLED
- Type
- 4inputs/4outputs
- Width
- 45 mm
- note
- Anexternaladditionalsupply(AUXPOWER)of20to30VDCisrequiredforthesupplyoftheoutputcircuits.TheadditionalsupplymustcomplywithVDE0106(PELV),protectionclassIII.
