3RT1265-6AF36
SKU: 3RT1265-6AF36
MPN: 3RT1265-6AF36
Key specs
View all- Size
- 210 MM Height x 145 MM Width x 202 MM Depth
- Wattage
- 132 KW At 400 V, 265 AMP
Description
Product overview
Contactor,IEC,Sirius,Vacuum 3 Pole,Non-Reversing 110 - 127 AC/DC Coil Frame Size S10,265A Panel Mount 2 NO ( & ) 2 NC Auxiliaries No Suppression Lugs (Not Included) Terminals UL File E31519 in Vol.11 Sec. 3
Contactor,IEC,Sirius,Vacuum 3 Pole,Non-Reversing 110 - 127 AC/DC Coil Frame Size S10,265A Panel Mount 2 NO ( & ) 2 NC Auxiliaries No Suppression Lugs (Not Included) Terminals UL File E31519 in Vol.11 Sec. 3
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A 3RT1265-6AF36 CONTACTOR VAC S10
- Invoice description
- CONTACTOR VAC S10 265A 110-127V 3P BAR
Specifications
- UPC
- 754554772950
- UNSPSC
- 39121529
- Country of Origin
- DE
- Size
- 210 MM Height x 145 MM Width x 202 MM Depth
- Wattage
- 132 KW At 400 V, 265 AMP
- Coil Voltage
- 110/127@40/60Hz V
- Connection
- Screw, bar
- Contact Configuration
- 3 NO Main, 2 NO 2 NC Auxillary
- Operating Cycles
- 10000000 of the contactor / typical, 10000000 of the contactor with added auxiliary switch block / typical, 5,000,000 of the contactor with added electronics-compatible auxiliary switch block / typical
- Operating Temperature
- -25 To 60 DEG C
- Phase
- 3
- Size
- 210 MM Height x 145 MM Width x 202 MM Depth
- Standard
- GOST, CCC, UL, KETI Listed, CSA Certified
- Sub Brand
- SIRIUS
- Wattage
- 132 KW At 400 V, 265 AMP
