3SE7140-1BD00-0AS0
SKU: 3SE7140-1BD00-0AS0
MPN: 3SE7140-1BD00-0AS0
Key specs
View all- Ambient temperature / during operation / maximum
- 70 °C
- Ambient temperature / during operation / minimum
- -25 °C
- Color / of top part of the enclosure
- grey
- Depth
- 89 mm
- Height
- 105 mm
- Number of NC contacts / for auxiliary contacts
- 1
Description
Product overview
Steute 1NO/1NC, red led, 115 V, safety cable-operated switch
Steute 1NO/1NC, red led, 115 V, safety cable-operated switch
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A 3SE7140-1BD00-0AS0 ROPE SW,RED
- Invoice description
- ROPE SW,RED 120VAC LED,1NC+1NO
Specifications
- UPC
- 754554770635
- UNSPSC
- 39122213
- Country of Origin
- DE
- Ambient temperature / during operation / maximum
- 70 °C
- Ambient temperature / during operation / minimum
- -25 °C
- Color / of top part of the enclosure
- grey
- Depth
- 89 mm
- Height
- 105 mm
- Number of NC contacts / for auxiliary contacts
- 1
- Number of NO contacts / for auxiliary contacts
- 1
- Number of indicator lights
- 1
- Protection class IP
- IP65
- Switching function / Latching
- Yes
