3UG4501-1AW30
SKU: 3UG4501-1AW30
MPN: 3UG4501-1AW30
Key specs
View all- Adjustable response value impedance / Full-scale value
- 200 kOhm
- Adjustable response value impedance / initial value
- 2 kOhm
- Ambient temperature / during storage / minimum
- -40 °C
- Buffering time / in the event of power failure / minimum
- 200 ms
- Continuous current / of the DIAZED fuse link of the output relay
- 4 A
- Relative metering precision
- 20 %
Description
Product overview
Analog monitoring relay fill level monitoring resistance monitoring from 2 to 200 kohm 0vershoot and undershoot 24 to 240 V AC/DC 50 to 60 HZ DC and AC 2-step or 1-step control tripping delay 0.5 to 10 s 1 change-over contact screw terminal successor product for 3ug3501
Analog monitoring relay fill level monitoring resistance monitoring from 2 to 200 kohm 0vershoot and undershoot 24 to 240 V AC/DC 50 to 60 HZ DC and AC 2-step or 1-step control tripping delay 0.5 to 10 s 1 change-over contact screw terminal successor product for 3ug3501
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A 3UG4501-1AW30 LIQUID LEVEL MONI
- Invoice description
- LIQUID LEVEL MONITOR, 5-100 KOHMS,120V
Specifications
- UPC
- 754554942803
- UNSPSC
- 39121521
- Country of Origin
- CZ
- Adjustable response value impedance / Full-scale value
- 200 kOhm
- Adjustable response value impedance / initial value
- 2 kOhm
- Ambient temperature / during storage / minimum
- -40 °C
- Buffering time / in the event of power failure / minimum
- 200 ms
- Continuous current / of the DIAZED fuse link of the output relay
- 4 A
- Relative metering precision
- 20 %
- Response time / maximum
- 300 ms
- Shock resistance / acc. to IEC 60068-2-27
- sinusoidalhalf-wave15g/11ms
- Type of electrical connection
- screw-typeterminals
- Wire length / of sensor / maximum
- 100 m
