SIEMENS LOW VOLTAGE 3VA UL MOLDED CASE CIRCUIT BREAKER WITH ELECTRONIC TRIP UNIT. 3VA63 FRAME WITH MEDIUM (CLASS M) BREAKING CAPACITY. 400A 4-POLE (18KAIC AT 600V) (35KAIC AT 480V). ETU320 TRIP UNIT LI. SPECIAL FEATURES WITHOUT LUGS. DIMENSIONS (W x H x D) IN 7.2 x 9.8 x 5.4.

Image colors may not be accurate.
Please see details, or call (800) 462-7733 for more information.

3VA6340-5HL41-0AA0

$4,293.97 / EA

manufacturer discounts
learn about discounts

  • $3,849.77 for $1,500.00+
  • $3,701.70 for $2,500.00+
  • $3,553.63 for $3,500.00+
Available to order

Local stock: 0
Lead time: over 7 working days

SIEMENS LOW VOLTAGE 3VA UL MOLDED CASE CIRCUIT BREAKER WITH ELECTRONIC TRIP UNIT. 3VA63 FRAME WITH MEDIUM (CLASS M) BREAKING CAPACITY. 400A 4-POLE (18KAIC AT 600V) (35KAIC AT 480V). ETU320 TRIP UNIT LI. SPECIAL FEATURES WITHOUT LUGS. DIMENSIONS (W x H x D) IN 7.2 x 9.8 x 5.4.

SIEMENS LOW VOLTAGE 3VA UL MOLDED CASE CIRCUIT BREAKER WITH ELECTRONIC TRIP UNIT. 3VA63 FRAME WITH MEDIUM (CLASS M) BREAKING CAPACITY. 400A 4-POLE (18KAIC AT 600V) (35KAIC AT 480V). ETU320 TRIP UNIT LI. SPECIAL FEATURES WITHOUT LUGS. DIMENSIONS (W x H x D) IN 7.2 x 9.8 x 5.4.

150

UPC
804766313370
UNSPSC
39121601
Country of Origin
CZ
Number Of Poles:
4
Type:
3VA6
Voltage Rating:
480 V
Connection:
punched copper bar without any lug
Continuous current / rated value:
400
Continuous current / rated value / maximum:
400.0A
Current Rating:
400A
Design of the operating mechanism:
togglehandle
Design of the overcurrent release:
ETU320
Design of the product:
Systemprotection
Frame:
400A
Height:
248
Interrupt Rating:
WITH 35kA INTERRUPTION RATING
Length:
7.24
Number Of Poles:
4
Operating current / at 40 °C / rated value:
400
Operating current / at 45 °C / rated value:
400
Operating current / at 50 °C / rated value:
400
Operating current / at 70 °C / rated value:
340
Overcurrent release / Protective functions:
LIN
Product component / display:
No
Product designation:
Molded-casecircuitbreaker
Product designation / according to UL file:
MJAE
Product extension / optional / motor drive:
Yes
Product function / Intrinsic device protection:
Yes
Product function / communication function:
No
Product function / other measurement function:
No
Protective function of the overcurrent release:
LI
Simaris relevant:
-
Standard:
UL
Sub Brand:
3VA
Suitability for use:
systemprotection
Trip Type:
ETU320 LI ADJUSTMENT KNOB
Type:
3VA6
Type of the driving mechanism / motor drive:
No
Voltage Rating:
480 V
Width:
184
circuit-breaker / Design:
3VA6
product brand name:
SENTRON

Recently Viewed

  • placeholder image

    3VA6340-5HL41-0AA0

    SIEMENS INDUSTRY, INC.
    SIEMENS LOW VOLTAGE 3VA UL MOLDED CASE CIRCUIT BREAKER WITH ELECTRONIC TRIP UNIT. 3VA63 FRAME WITH MEDIUM (CLASS M) BREAKING CAPACITY. 400A 4-POLE (18...
    See more details
  • placeholder image

    3SU10313AB420AN0

    SIEMENS INDUSTRY, INC.
    ILLUMINATED TWIN PUSHBUTTON, 22MM, ROUND, PLASTIC WITH METAL FRONT RING, RED ARROW UP, GREEN ARROW DOWN, FLAT BUTTONS
