5451A
SKU: 5451A
MPN: 5451A
Key specs
View all- Type
- Inline
- Voltage Rating
- 25,000/28,000 V
Description
Product overview
The 3M™ Molded Rubber QS-II Inline CN/JCN Cable Splice Kits 5450 Series kits are one-piece inline splices designed for use on 25/28 kV CN and JCNcable. Meets requirements of IEEE 404 for cable joints.The splice is a one-piece molded design made of specially formulated, peroxide cured EPDM rubbers. Each splice is production tested on CN cable to ensure reliability. Each kit makes one splice. Jacketing kit is needed for JCN cable. Connectors, unless specfied, are not included in the kit, and must...
The 3M™ Molded Rubber QS-II Inline CN/JCN Cable Splice Kits 5450 Series kits are one-piece inline splices designed for use on 25/28 kV CN and JCNcable. Meets requirements of IEEE 404 for cable joints.The splice is a one-piece molded design made of specially formulated, peroxide cured EPDM rubbers. Each splice is production tested on CN cable to ensure reliability. Each kit makes one splice. Jacketing kit is needed for JCN cable. Connectors, unless specfied, are not included in the kit, and must be ordered separately. Refer to the index to find CI, CI-840 and CI-A series connectors.Note: Cable sizes shown below are for standard insulation thickness. Final determining factor is cable insulation O.D.
Manufacturer highlights
- Jacketing kit is required for JCN cable
- Meets the requirements of IEEE 404 standards for cable joints
- Computer design ensures a compact size and optimal distribution of the electrical field
- Designed for direct burial installations, aerial installations and submerged locations
Additional manufacturer notes
- Short name
- 3M
- Feed description
- 3M 5451A KIT, 5451A
- Label description
- 3M(TM) Molded Rubber Splices 5451A, 2,1,1/0,2/0 AWG Stranded, 1,1/0 AWG Solid, 0.905-1.055 in, 1 per case
- Invoice description
- KIT, 5451A
Specifications
- UPC
- 054007495277
- UNSPSC
- 26121649
- Country of Origin
- USA
- Type
- Inline
- Voltage Rating
- 25,000/28,000 V
- Cable Type
- Concentric Neutral (CN); Jacketed Concentric Neutral (JCN)
- Conductor Size
- 1 AWG(295 mils); 1/0 AWG (280 mils); 1/0 AWG (295 mils)
- Connector
- None
- Insulation OD Range
- 0.905 - 1.055 Inch
- Number of Conductors
- 1
- Product Technology
- Molded Rubber
- Type
- Inline
- Voltage Rating
- 25,000/28,000 V
