5641-1/0
SKU: 5641-1/0
MPN: 5641-1/0
Key specs
View all- Type
- QT-II
- Voltage Rating
- 15,000 V
Description
Product overview
3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages up to 15kV.
3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages up to 15kV.
Manufacturer highlights
- One-piece cold shrink termination.
- High dielectric-constant material regulates the distribution of electric field stress
- Suitable for outdoor, weather exposed applications
- Silicone rubber insulation is track-resistance and hydrophobic
Additional manufacturer notes
- Short name
- 3M
- Feed description
- 3M 5641-1/0 5641 1/0 -P60
- Label description
- 3M(TM) Cold Shrink QTII Outdoor Termination Kit 5641-1/0, 15 kV, 0.637-1.12 in (16-28 mm) Cable Insulation O.D.
- Invoice description
- 5641 1/0 -P60
Specifications
- UPC
- 054007119647
- UNSPSC
- 26121648
- Country of Origin
- USA
- Type
- QT-II
- Voltage Rating
- 15,000 V
- Cable Type
- Jacketed Concentric Neutral (JCN)
- Conductor Size
- 1/0 AWG
- Number Of Terminals
- 1
- Standard
- IEEE
- Type
- QT-II
- Voltage Rating
- 15,000 V
