Videos & documents
Documents
8522
SKU: 8522
MPN: 8522
Key specs
View all- Material
- Galvanized Steel
- Size
- 1-1/2 IN
- Type
- EMT 22-1/2 DEG Angle Elbow
Description
Product overview
1 1/2" EMT 22 1/2 DEGREE ELBOW 20PK - GALVANIZED STEEL
1 1/2" EMT 22 1/2 DEGREE ELBOW 20PK - GALVANIZED STEEL
Manufacturer highlights
Topazs 22.5 elbow is precision manufactured from EMT conduit that conforms to the latest specifications and standards to deliver optimum safety and pe...
Topazs 22.5 elbow is precision manufactured from EMT conduit that conforms to the latest specifications and standards to deliver optimum safety and performance in all applications. Fabricated from galvanized steel for low conductivity and high corrosion resistance, all surfaces, both interior and exterior are defect free to ensure a secure connection to EMT conduit and to preserve integrity and longevity. Available in sizes from 1-1/4 to 4; cULus approved, meets Federal specification WW-C-563.
Additional manufacturer notes
- Feed description
- TPZ 8522 1 1/2" EMT 22 1/2 DEG ELBO
- Invoice description
- 1 1/2" EMT 22 1/2 DEG ELBOW 15PK
Specifications
- UPC
- 751338838901
- UNSPSC
- 39121464
- Country of Origin
- MUL
- Material
- Galvanized Steel
- Size
- 1-1/2 IN
- Type
- EMT 22-1/2 DEG Angle Elbow
- Bend Angle
- 22-1/2 DEG
- Bend Radius
- 8.25 IN
- Label Description
- 22.5° EMT ELBOW
- Leg Length
- 2.781 IN
- Material
- Galvanized Steel
- Size
- 1-1/2 IN
- Size (IN)
- 1-1/2" IN
- Standard
- UL 514B, UL File Number E197604, US Federal Specification Number A-A-50552, CSA Certified, NEMA/ANSI FB-1, Military Specification:W-F-406D, W-F-406E, W-F-408D, W-S-610D, UL 797, ANSI C80.3, Federal Specification WW-C-563
- Type
- EMT 22-1/2 DEG Angle Elbow
- Manufacturer keywords
- 1 1/2" EMT 22 1/2 DEG ELBOW 20
Do you have a question about 8522?
Videos & documents
Documents
Similar items
Compare alternates in this category before ordering.
Similar item
25TZ
1-1/2" EMT 45 DEGREE ELBOW - GALVANIZED STEEL 50-PK
$7.29 / EA
Available to order
Similar item
8530
1 1/2" EMT 30 DEGREE ELBOW 20PK - GALVANIZED STEEL
$7.29 / EA
Available to order
Specification comparison
Scan the attributes that differ across these alternatives.
9110-ARL View key specs Hide specs
- SKU
- 9110-ARL
- Price
-
$13.26 / EA
- Availability
- Available to order
- Bend Angle
- —
- Bend Radius
- —
- Label Description
- —
- Leg Length
- —
- Material
- Zinc
- Size
- L(2.232) x W(2.082) x H(1.300) IN
25TZ View key specs Hide specs
- SKU
- 25TZ
- Price
-
$7.29 / EA
- Availability
- Available to order
- Bend Angle
- 45 DEG
- Bend Radius
- 8.250 IN
- Label Description
- 45° EMT ELBOW
- Leg Length
- 3.625 IN
- Material
- Galvanized Steel
- Size
- 1-1/2 IN
26TZ View key specs Hide specs
- SKU
- 26TZ
- Price
-
$11.56 / EA
- Availability
- Available to order
- Bend Angle
- 45 DEG
- Bend Radius
- 9.500 IN
- Label Description
- 45° EMT ELBOW
- Leg Length
- 4.1875 IN
- Material
- Galvanized Steel
- Size
- 2 IN
27TZ View key specs Hide specs
- SKU
- 27TZ
- Price
-
$28.03 / EA
- Availability
- 2 available
- Bend Angle
- 45 DEG
- Bend Radius
- 10.5 IN
- Label Description
- 45° EMT ELBOW
- Leg Length
- 5.25 IN
- Material
- Galvanized Steel
- Size
- 2-1/2 IN
29TZ View key specs Hide specs
- SKU
- 29TZ
- Price
-
$56.42 / EA
- Availability
- Available to order
- Bend Angle
- 45 DEG
- Bend Radius
- 15 IN
- Label Description
- 45° EMT ELBOW
- Leg Length
- 6.75 IN
- Material
- Galvanized Steel
- Size
- 3-1/2 IN
8530 View key specs Hide specs
- SKU
- 8530
- Price
-
$7.29 / EA
- Availability
- Available to order
- Bend Angle
- 30 DEG
- Bend Radius
- 8.25 IN
- Label Description
- 30° EMT ELBOW
- Leg Length
- 2.781 IN
- Material
- Galvanized Steel
- Size
- 1-1/2 IN
