Videos & documents
Documents
875
SKU: 875-TOPAZ
MPN: 875
Key specs
View all- Material
- Die Cast Zinc
- Size
- 1-1/2 IN
- Type
- Compression Water Tight Connector
Description
Product overview
1-1/2" Compression Type Watertight Connectors
1-1/2" Compression Type Watertight Connectors
Manufacturer highlights
Make the secure connection with the Topaz line of high performing, easy to install Compression Type Watertight Connectors. Featuring high quality, cor...
Make the secure connection with the Topaz line of high performing, easy to install Compression Type Watertight Connectors. Featuring high quality, corrosion resistant zinc die cast construction with rubber grommet. For wire sizes 3 # 8 through 3 # 4/0. UL listed and built to last; always in stock and ready for fast delivery.
- Compression type
- Rubber grommet
- Compression type
- Rubber grommet
Additional manufacturer notes
- Short name
- TPZ
- Feed description
- TPZ 875 1-1/2WATERTIGHT CON 5/50PK
- Invoice description
- 1-1/2WATERTIGHT CON 5/50PK
Specifications
- UPC
- 751338188105
- UNSPSC
- 39121420
- Country of Origin
- MUL
- Material
- Die Cast Zinc
- Size
- 1-1/2 IN
- Type
- Compression Water Tight Connector
- CSA - U.S.
- UL CSA
- Conductor Range
- 1/0 AWG
- Connection
- Threaded
- Connectors (IN)
- Threaded IN
- For Use With
- TYPE SE Cable, STYLE U Flat Cable
- Grommet Opening Size
- 0.705 x 1.195 IN
- Height
- 2.375 IN
- Insulation
- None
- Label Description
- WATERTIGHT CONNECTOR-COMPRESSION TYPE
- Material
- Die Cast Zinc
- Max Number of Conductors
- 1/0 AWG
- Number Of Conductors
- 3
- Size
- 1-1/2 IN
- Size (IN)
- 3#1/0 IN
- Standard
- UL 514B, UL File Number E148711, US Federal Specification Number A-A-50552, CSA Certified, NEMA/ANSI FB-1, Military Specification:W-F-406D, W-F-406E, W-F-408D, W-S-610D
- Type
- Compression Water Tight Connector
- Manufacturer keywords
- 1-1/2WATERTIGHT CON 5/50PK
