DM-200A-C
SKU: DM-200A-C
MPN: DM-200A-C
Key specs
View all- Type
- Digital
Description
Product overview
ESM™ Series Digital Multimeters. Includes Certificate of Calibration. Measures voltage, current, resistance and frequency. Tests continuity and diodes. Backlit LCD with 6,000 count display. Two voltage detection modes - non-contact or using a single test lead. BeepJack™ warns when test leads are incorrectly inserted in current measurement terminals. Automatic and manual range selection. Relative offset mode to see changes in measurements. Data hold. Use optional USB / RS-232 interface...
ESM™ Series Digital Multimeters. Includes Certificate of Calibration. Measures voltage, current, resistance and frequency. Tests continuity and diodes. Backlit LCD with 6,000 count display. Two voltage detection modes - non-contact or using a single test lead. BeepJack™ warns when test leads are incorrectly inserted in current measurement terminals. Automatic and manual range selection. Relative offset mode to see changes in measurements. Data hold. Use optional USB / RS-232 interface DMSC-2U for direct-to-PC logging. Lifetime Limited Warranty. Accessories included: (2)1.5V AAA batteries, test leads and protective boot.
Manufacturer highlights
Additional manufacturer notes
- Feed description
- GRN DM-200A-C DMM,1KV AC/DC(DM-200A
- Label description
- Digital Multimeter
- Invoice description
- DMM,1KV AC/DC(DM-200A)(CALIB)
Specifications
- UPC
- 783310357568
- UNSPSC
- 41113630
- Country of Origin
- TW
- Type
- Digital
- Amperage Measurement
- 600, 6000μA; 60, 600mA; 6, 8A
- Battery
- (2) 1.5 V AAA
- Capacitance
- 60, 600nF; 6, 60, 600, 3000μF
- Display
- Backlit LCD With 6,000 Count
- Frequency Measurement
- 10Hz - 50kHz Sine Wave, 5Hz- 999.9kHz Logic Level Square Wave
- Includes
- (2) 1.5V AAA Batteries, Bead Temperature Probe (DM-210A, DM-510A Only, 400°F/204°C max), Test leads, Protective Boot
- Measurement Category
- CAT IV 300 V, CAT III 600 V, CAT II 1000 V
- Replacement Part
- TSG-3 Sure-Grip Test Leads
- Resistance Measurement
- 600Ω; 6, 60, 600 kΩ; 6, 60 MΩ
- Standard
- CAT IV, CAT III, CAT II, C/ULUS Listed, CE Listed
- Sub Brand
- ESM
- Temperature Rating
- K Type, -58 To 1832°F (-50 To 1000°C)
- Type
- Digital
- Voltage Measurement
- 60, 600 mV; 6, 60, 600, 1000V
- Manufacturer keywords
- 35756,DM200AC
