ECD00-FUS

SKU: ECD00-FUS

MPN: ECD00-FUS

Description

Product overview

For use with ECD00-D0W. Fuse and fuseholder accessory kit includes two fuses, a UL listed holder, and fuse puller. Required to meet UL1008 requirements for Short Circuit Current Rating (5000A). The fuse is installed on the line side of the dimming control. Under this method, a single ECD00-FUS may feed multiple ECD00-D0Ws, provided that their total load does not exceed 16A, and they share the same normal and emergency breakers. Fuses are 30 Amps

For use with ECD00-D0W. Fuse and fuseholder accessory kit includes two fuses, a UL listed holder, and fuse puller. Required to meet UL1008 requirements for Short Circuit Current Rating (5000A). The fuse is installed on the line side of the dimming control. Under this method, a single ECD00-FUS may feed multiple ECD00-D0Ws, provided that their total load does not exceed 16A, and they share the same normal and emergency breakers. Fuses are 30 Amps

Manufacturer highlights

Additional manufacturer notes

Short name
LEV
Feed description
LEV ECD00-FUS EB FUSE AND FUSE HOLD
Invoice description
EB FUSE AND FUSE HOLDER KIT

Specifications

UPC
078477925690
UNSPSC
39121107
Country of Origin
MX
