FWH-450A
SKU: FWH-450A-EDF
MPN: FWH-450A
Key specs
View all- Amperage Rating
- 450A RMS
- Size
- 2.00 In Diameter X 4.34 In Length
- Type
- High speed fuse
- Voltage Rating
- 750 Vac, 750 Vdc
Description
Product overview
Eaton Bussmann series FWH high speed fuse, 750 Vac, 750 Vdc, 450A RMS, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Eaton Bussmann series FWH high speed fuse, 750 Vac, 750 Vdc, 450A RMS, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Manufacturer highlights
High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristor...
High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.
Additional manufacturer notes
- Short name
- BUSS
- Feed description
- BUSS FWH-450A BUSS HIGH SPEED FUSE
- Invoice description
- BUSS HIGH SPEED FUSE
Specifications
- UPC
- 051712150194
- UNSPSC
- 39121628
- Country of Origin
- MX
- Amperage Rating
- 450A RMS
- Size
- 2.00 In Diameter X 4.34 In Length
- Type
- High speed fuse
- Voltage Rating
- 750 Vac, 750 Vdc
- Amperage Rating
- 450A RMS
- Connection
- Blade end x blade end
- Dimensions
- 2.1700 IN X 5.3000 IN X 2.8000 IN
- Interrupt Rating
- 50 kAIC at 500 Vdc200 kAIC at 1000 Vac
- Mounting
- Stud
- Size
- 2.00 In Diameter X 4.34 In Length
- Standard
- UL Recognized ,CSA Certified,CE Marked,RoHS Compliant
- Sub Brand
- Bussmann Series
- Type
- High speed fuse
- Voltage Rating
- 750 Vac, 750 Vdc
