$414.12 / EA
In stock (0)
Lead time: over 7 days
may be longer on small orders
Eaton Bussmann series FWP high speed fuse, 250 Vac/dc, 500A RMS, 200 kAIC Vac, 50 kAIC at 700 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Eaton Bussmann series FWP high speed fuse, 250 Vac/dc, 500A RMS, 200 kAIC Vac, 50 kAIC at 700 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
High speed fuses provide superior protection or isolation for components such as diodes, silicon con...150
High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.
- UPC
- 051712150453
- UNSPSC
- 39121628
- Country of Origin
- MX
- Amperage Rating:
- 500A RMS
- Size:
- 2.50 In Diameter X 7.09 In Length
- Type:
- High speed fuse
- Voltage Rating:
- 250 VAC//VDC
- Amperage Rating:
- 500A RMS
- Connection:
- Blade end x blade end
- Dimensions:
- 7.5000 IN X 2.5500 IN X 2.5500 IN
- Interrupt Rating:
- 50 kAIC at 700 Vdc200 kAIC Vac
- Mounting:
- Stud
- Size:
- 2.50 In Diameter X 7.09 In Length
- Standard:
- UL Recognized ,CSA Certified,CE Marked,RoHS Compliant
- Sub Brand:
- Bussmann Series
- Type:
- High speed fuse
- Voltage Rating:
- 250 VAC//VDC
KAW-30
$126.57 /ea
Eaton Bussmann series KAW semiconductor fuse, 30 A
| Attributed Data | Included |
|---|---|
| Dimensions | 0.3600 IN X 0.3600 IN X 1.5000 IN Yes |
| Standard | Contact factory,Contact Manufacturer Yes |
| Sub Brand | Bussmann Series Yes |
| Type | Semiconductor fuse Yes |
FWC-25A10F
$27.03 /ea
Eaton Bussmann series FWC high speed cylindrical fuse, 500 Vac/dc (35-800A only), 25A, 200 kAIC Vac, 50 kAIC at 700 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end
| Attributed Data | Included |
|---|---|
| Connection | Ferrule end x ferrule end Yes |
| Dimensions | 1.4961 IN X 0.4331 IN X 0.4331 IN Yes |
| Interrupt Rating | 50 kAIC at 700 Vdc200 kAIC Vac Yes |
| Size | 0.406 In Diameter X 1.500 In Length Yes |
| Standard | UL Recognized ,CSA Certified,CE Marked Yes |
| Sub Brand | Bussmann Series Yes |
| Type | High speed cylindrical fuse Yes |
FWC-32A10F
$27.03 /ea
Eaton Bussmann series FWC high speed cylindrical fuse, 600V (UL), 32A, 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end, Class aR, White, Ceramic
| Attributed Data | Included |
|---|---|
| Class | Class aR Yes |
| Connection | Ferrule end x ferrule end Yes |
| Dimensions | 1.4961 IN X 0.4331 IN X 0.4331 IN Yes |
| Interrupt Rating | 50 kAIC at 300 Vdc200 kAIC at 300 Vdc Yes |
| Material | Ceramic Yes |
| Size | 0.406 In Diameter X 1.500 In Length Yes |
| Standard | CSA Certified ,UL Recognized,CE Marked,RoHS Compliant Yes |
| Sub Brand | Bussmann Series Yes |
| Type | High speed cylindrical fuse Yes |
| Product Image |
|
|
|
|
|---|---|---|---|---|
|
KAW-30
Eaton Bussmann series KAW semiconductor fuse, 30 A
$126.57 / EA
|
FWC-25A10F
Eaton Bussmann series FWC high speed cylindrical fuse, 500 Vac/dc (35-800A only), 25A, 200 kAIC Vac, 50 kAIC at 700 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end
$27.03 / EA
|
FWC-32A10F
Eaton Bussmann series FWC high speed cylindrical fuse, 600V (UL), 32A, 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end, Class aR, White, Ceramic
$27.03 / EA
|
||
| Attributed Data | ||||
| Amperage Rating | 25 A 25 A | 30 A 30 A | 32 A 32 A | |
| Class | Class aR Class aR | |||
| Connection | Ferrule end x ferrule end Ferrule end x ferrule end | |||
| Dimensions | 0.3600 IN X 0.3600 IN X 1.5000 IN 0.3600 IN X 0.3600 IN X 1.5000 IN | 1.4961 IN X 0.4331 IN X 0.4331 IN 1.4961 IN X 0.4331 IN X 0.4331 IN | ||
| Interrupt Rating | 50 kAIC at 300 Vdc200 kAIC at 300 Vdc 50 kAIC at 300 Vdc200 kAIC at 300 Vdc | 50 kAIC at 700 Vdc200 kAIC Vac 50 kAIC at 700 Vdc200 kAIC Vac | ||
| Material | Ceramic Ceramic | |||
| Size | 0.406 In Diameter X 1.500 In Length 0.406 In Diameter X 1.500 In Length | |||
| Standard | CSA Certified ,UL Recognized,CE Marked,RoHS Compliant CSA Certified ,UL Recognized,CE Marked,RoHS Compliant | CSA Certified,UL Recognized,CE Marked,RoHS Compliant CSA Certified,UL Recognized,CE Marked,RoHS Compliant | Contact factory,Contact Manufacturer Contact factory,Contact Manufacturer | UL Recognized ,CSA Certified,CE Marked UL Recognized ,CSA Certified,CE Marked |
| Sub Brand | Bussmann Series Bussmann Series | |||
| Type | High speed cylindrical fuse High speed cylindrical fuse | Semiconductor fuse Semiconductor fuse | ||
| Voltage Rating | 600 V 600 V | |||
| Add a product to the cart | Show more details | Show more details | Show more details | |
