$88.94 / EA
In stock (0)
Lead time: over 7 days
may be longer on small orders
Eaton Bussmann series FWX high speed fuse, 100A RMS, 200 kAIC Vac, 50 kAIC at 250 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Eaton Bussmann series FWX high speed fuse, 100A RMS, 200 kAIC Vac, 50 kAIC at 250 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
High speed fuses provide superior protection or isolation for components such as diodes, silicon con...150
High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.
- UPC
- 051712150637
- UNSPSC
- 39121628
- Country of Origin
- MX
- Amperage Rating:
- 100A RMS
- Size:
- 1.22 In Diameter X 3.13 In Length
- Type:
- High speed fuse
- Voltage Rating:
- 250 VAC//VDC
- Amperage Rating:
- 100A RMS
- Connection:
- Blade end x blade end
- Dimensions:
- 3.1100 IN X 1.2300 IN X 3.1100 IN
- Interrupt Rating:
- 200 kAIC Vac50 kAIC at 250 Vdc
- Mounting:
- Stud, Flush
- Size:
- 1.22 In Diameter X 3.13 In Length
- Standard:
- UL Recognized ,CSA Certified,RoHS Compliant,CE Marked
- Sub Brand:
- Bussmann Series
- Type:
- High speed fuse
- Voltage Rating:
- 250 VAC//VDC
