HGB3B050B
SKU: HGB3B050B
MPN: HGB3B050B
Key specs
View all- Number Of Poles
- 3
Description
Product overview
SIEMENS LOW VOLTAGE PANELBOARD MOUNT G FRAME CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP. UL LISTED HGB FRAME WITH HIGH BREAKING CA PACITY. 50A 3-POLE (14KAICAT 600Y/347V) (35KAIC AT 480Y/277V). SPECIAL FEATURES MOUNTS ON PANELBOARD, LOAD SIDE LUGS ONLY (TC1GG20) WIRE RANGE 8 - 1/0 AWS (CU/AL). DIMENSIONS (W x H x D) IN 3 x 5.4 x 2.8.
SIEMENS LOW VOLTAGE PANELBOARD MOUNT G FRAME CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP. UL LISTED HGB FRAME WITH HIGH BREAKING CA PACITY. 50A 3-POLE (14KAICAT 600Y/347V) (35KAIC AT 480Y/277V). SPECIAL FEATURES MOUNTS ON PANELBOARD, LOAD SIDE LUGS ONLY (TC1GG20) WIRE RANGE 8 - 1/0 AWS (CU/AL). DIMENSIONS (W x H x D) IN 3 x 5.4 x 2.8.
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A HGB3B050B BRKR HGB 50A 3P 480Y
- Invoice description
- BRKR HGB 50A 3P 480Y 35K LD LUG
Specifications
- UPC
- 887621219833
- UNSPSC
- 39121601
- Country of Origin
- MX
- Number Of Poles
- 3
- Continuous current / rated value
- 50 A
- Design of the overload release
- THERMAL-MAGNETIC
- Design of the product
- MOLDEDCASECIRCUITBREAKER
- Height [in]
- 5.4 in
- Mounting type
- PANELBOARDBUS
- Number Of Poles
- 3
- Standard
- UL/CSA/IEC/NOM
- Suitability for operation
- ELECTRICALDISTRIBUTION
- Tripping characteristic class
- HIGH
- Voltage / between phase and Ground (GND) / rated value
- 347 V
- Voltage / between phase and phase / rated value
- 600 V
- Width [in]
- 3 in
