Q230
SKU: Q230
MPN: Q230
Key specs
View all- Number Of Poles
- 2
- Type
- QP
- Voltage Rating
- 120 V
Description
Product overview
Siemens Low Voltage Residential Circuit Breakers Miniature Thermal Mag Circuit Breakers - Type QP/MP, 2-Pole, 120/240VAC are Circuit Protection Load Center Mains, Feeders, and Miniature Circuit Breakers. LS-SCHALTER 10KA 1POL C20
Siemens Low Voltage Residential Circuit Breakers Miniature Thermal Mag Circuit Breakers - Type QP/MP, 2-Pole, 120/240VAC are Circuit Protection Load Center Mains, Feeders, and Miniature Circuit Breakers. LS-SCHALTER 10KA 1POL C20
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A Q230 BREAKER 30A 2P 120/240V 10
- Invoice description
- BREAKER 30A 2P 120/240V 10K QP
Specifications
- UPC
- 783643148383
- UNSPSC
- 39121601
- Country of Origin
- MX
- Number Of Poles
- 2
- Type
- QP
- Voltage Rating
- 120 V
- Conductor Size
- 14-6AWG(CU)/12-6AWG(AL)
- Connection
- PLUG-IN
- Continuous current / rated value
- 30 A
- Frame
- QP(125A)
- Height [in]
- 2.87 in
- Length
- 3 in
- Number Of Poles
- 2
- Standard
- ULLISTED/CSA/NOMCERTIFIED
- Supply voltage frequency / rated value / 50/60 Hz
- TRUE
- Trip Type
- THERMAL-MAGNETIC
- Type
- QP
- Type of mounting panel
- LOADCENTER
- Voltage / between phase and phase / rated value
- 240 V
- Voltage Rating
- 120 V
- Width
- 2 in
