MTK
SKU: MTK
MPN: MTK
Key specs
View all- Color
- Blue/Red/Yellow
- Material
- Vinyl Insulation
- Type
- Miniterm Kit
- Voltage Rating
- 300 V
Description
Product overview
NSi Industries Vinyl Insulated 493-Piece Miniterm Kit The NSi Industries Vinyl Insulated 493-Piece Miniterm Kit has been carefully designed to include the most popular NSi miniterm terminals. The cases are made of extremely durable polypropylene. They provide the ultimate in organization and convenience. Miniterms are clearly labeled on the inside lid for easy recognition. Convenient size for easy carrying and easy storing. Refillable and reusable. KIT CONTAINS: Quantity SKU Type Wire Size Stud/...
NSi Industries Vinyl Insulated 493-Piece Miniterm Kit The NSi Industries Vinyl Insulated 493-Piece Miniterm Kit has been carefully designed to include the most popular NSi miniterm terminals. The cases are made of extremely durable polypropylene. They provide the ultimate in organization and convenience. Miniterms are clearly labeled on the inside lid for easy recognition. Convenient size for easy carrying and easy storing. Refillable and reusable. KIT CONTAINS: Quantity SKU Type Wire Size Stud/Tab Size Length Width 40 R22-6V Vinyl Insulated Ring Terminal 22-18 6 .831 .315 40 R22-10V Vinyl Insulated Ring Terminal 22-18 10 .827 .315 30 R16-6V Vinyl Insulated Ring Terminal 16-14 6 .717 .256 30 R16-10V Vinyl Insulated Ring Terminal 16-14 10 .846 .315 20 R12-8V Vinyl Insulated Ring Terminal 12-10 8 1.063 .374 20 R12-14V Vinyl Insulated Ring Terminal 12-10 1/4 1.201 .472 40 F22-250-3V Vinyl Insulated Female Disconnect 22-18 .250 x.032 - - 35 F16-250-3V Vinyl Insulated Female Disconnect 16-14 .250 x.032 - - 20 F12-250-3V Vinyl Insulated Female Disconnect 12-10 .250 x.032 - - 35 B22-V Vinyl Insulated Butt Connector 22-18 - 1.004 - 25 B16-V Vinyl Insulated Butt Connector 16-14 - 1.004 - 15 B12-V Vinyl Insulated Butt Connector 12-10 - 1.063 - 40 S22-6V Vinyl Insulated Spade Terminal 22-18 6 .896 .224 40 S22-10V Vinyl Insulated Spade Terminal 22-18 10 .906 .378 25 S16-6V Vinyl Insulated Spade Terminal 16-14 6 .839 .252 25 S16-10V Vinyl Insulated Spade Terminal 16-14 10 .846 .315 15 S12-8V Vinyl Insulated Spade Terminal 12-10 8 1.012 .354 12 S12-14V Vinyl Insulated Spade Terminal 12-10 1/4 1.287 .354
Manufacturer highlights
Additional manufacturer notes
- Short name
- NSI
- Feed description
- NSI MTK Miniterm Kit
- Invoice description
- Miniterm Kit
Specifications
- UPC
- 662381086006
- Color
- Blue/Red/Yellow
- Material
- Vinyl Insulation
- Type
- Miniterm Kit
- Voltage Rating
- 300 V
- Color
- Blue/Red/Yellow
- Environmental Conditions
- 75 C
- Material
- Vinyl Insulation
- Number Of Terminals
- 1
- Standard
- cULus
- Sub Brand
- Miniterms
- Type
- Miniterm Kit
- Voltage Rating
- 300 V
- Wire Size
- 22-18, 16-14, 12-10 AWG
