Image colors may not be accurate.
Please see details, or call (800) 462-7733 for more
information.
$1,986.50 / EA
manufacturer discounts
learn about discounts
- $1,781.00 for $1,500.00+
- $1,712.50 for $2,500.00+
- $1,644.00 for $3,500.00+
In stock (0)
Lead time: over 7 days
may be longer on small orders
SIEMENS LOW VOLTAGE PANELBOARD MOUNT G FRAME CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP. NON UL NGB FRAME WITH STANDARD BREAKING C APACITY. 80A 3-POLE (14KAIC AT 600Y/347V) (25KAIC AT 480Y/277V). SPECIAL FEATURES MOUNTS ON PANELBOARD, 50DEG CALIBRATION, LOAD SIDE LUGS ONLY (TC1GG20) WIRE RANGE 8 - 1/0 AWS (CU/AL). DIMENSIONS (W x H x D) IN 3 x 5.4 x 2.8.
SIEMENS LOW VOLTAGE PANELBOARD MOUNT G FRAME CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP. NON UL NGB FRAME WITH STANDARD BREAKING C APACITY. 80A 3-POLE (14KAIC AT 600Y/347V) (25KAIC AT 480Y/277V). SPECIAL FEATURES MOUNTS ON PANELBOARD, 50DEG CALIBRATION, LOAD SIDE LUGS ONLY (TC1GG20) WIRE RANGE 8 - 1/0 AWS (CU/AL). DIMENSIONS (W x H x D) IN 3 x 5.4 x 2.8.
150
- UPC
- 040892059106
- UNSPSC
- 39121601
- Country of Origin
- MX
- Number Of Poles:
- 3
- Continuous current / rated value:
- 80 A
- Design of the overload release:
- THERMAL-MAGNETIC
- Design of the product:
- MOLDEDCASECIRCUITBREAKER
- Height [in]:
- 5.4 in
- Mounting type:
- PANELBOARDBUS
- Number Of Poles:
- 3
- Standard:
- CSA/IEC/NOM
- Suitability for operation:
- ELECTRICALDISTRIBUTION
- Tripping characteristic class:
- STANDARD
- Voltage / between phase and Ground (GND) / rated value:
- 347 V
- Voltage / between phase and phase / rated value:
- 600 V
- Width [in]:
- 3 in
