$890.24 / EA
manufacturer discounts
learn about discounts
- $798.15 for $1,500.00+
- $767.45 for $2,500.00+
- $736.75 for $3,500.00+
Local stock: 0
Lead time:
over 7 working days
SIEMENS LOW VOLTAGE G FRAME CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP. UL LISTED NGG FRAME WITH STANDARD BREAKING CAPACITY. 90A 1-POLE (14KAIC AT 347V) (25KAIC AT 277V). SPECIAL FEATURES MOUNTS ON DIN RAIL / SCREW, LINE AND LOAD SIDE LUGS (TC1GG20) WIRE RANGE 8 - 1/0 AWS (CU/AL). DIMENSIONS (W x H x D) IN 1 x 5.4 x2.8.
SIEMENS LOW VOLTAGE G FRAME CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP. UL LISTED NGG FRAME WITH STANDARD BREAKING CAPACITY. 90A 1-POLE (14KAIC AT 347V) (25KAIC AT 277V). SPECIAL FEATURES MOUNTS ON DIN RAIL / SCREW, LINE AND LOAD SIDE LUGS (TC1GG20) WIRE RANGE 8 - 1/0 AWS (CU/AL). DIMENSIONS (W x H x D) IN 1 x 5.4 x2.8.
150
- UPC
- 783643413597
- UNSPSC
- 39121601
- Country of Origin
- MX
- Number Of Poles:
- 1
- Continuous current / rated value:
- 90 A
- Depth [in]:
- 2.8 in
- Design of the overload release:
- THERMAL-MAGNETIC
- Design of the product:
- MOLDEDCASECIRCUITBREAKER
- Height [in]:
- 5.4 in
- Mounting type:
- DINRAIL/SCREW
- Number Of Poles:
- 1
- Standard:
- UL/CSA/IEC/NOM
- Suitability for operation:
- ELECTRICALDISTRIBUTION
- Tripping characteristic class:
- STANDARD
- Voltage / between phase and Ground (GND) / rated value:
- 347 V
- Width [in]:
- 1 in
