$183.64 / EA
In stock (0)
Lead time: over 7 days
may be longer on small orders
Our 3M™ Fire Barrier Plank PK39 is a pre-formed foam plank designed for easy installation to effectively seal larger openings against smoke, toxic gas and flame. It is simple to use and helps reduce sound transmission.
Our 3M™ Fire Barrier Plank PK39 is a pre-formed foam plank designed for easy installation to effectively seal larger openings against smoke, toxic gas and flame. It is simple to use and helps reduce sound transmission.
A Better Way to Fill Large GapsWhen sealing larger cavities, use 3M™ Fire Barrier Plank PK39 t...150
A Better Way to Fill Large GapsWhen sealing larger cavities, use 3M™ Fire Barrier Plank PK39 to restore the integrity of the wall with a simple "stack, seal, and done" application, without the use of special tools. The blocks are engineered to remain securely in place, eliminating traditional wire mesh reinforcements. Pre-formed blocks help technicians fill large openings quickly. The material is easy to trim on site without special tools, achieving a tight, custom fit. No cure time is required, which means installation is completed faster, and the blocks are paintable with primer for a more seamless appearance.The blocks are fully re-enterable and reusable, saving time and money, while minimizing waste. Once the opening is filled, seal around the perimeter and any penetrating items with 3M™ Fire Barrier Rated Foam FIP 1-Step or other 3M™ fire barrier sealants (sold separately).Recommended Applications Blank openings Metal pipes Cables Cable trays Insulated pipes, combination penetrationsFully Tested and Approved3M™ Fire Barrier Plank PK39 are firestop tested to the criteria of ASTM E 814/UL 1479 Standard Test Method for Fire Tests of Penetration Firestop Systems, ASTM E 84/UL 273 Standard Test Method for Surface Burning Characteristics of Building Materials, ASTM E 90 Standard Test Method for Laboratory Measurement of Airborne Sound Transmission Loss of Building Partitions and Elements, and ASTM E 413 Classification for Rating Sound Insulation. Reliable and Affordable Fire Protection Effective and easy to install, 3M™ Fire Barrier Plank PK39 are part of our family of fire protection products that offer the broadest, long-lasting solutions for a variety of commercial, industrial and residential applications. As a trusted leader in the fire protection industry, 3M offers a broad line of affordable products designed to meet the most demanding firestop requirements. Find the solution you need from the industry-preferred line of fire protection products.
- Pre-formed foam 1 meter (approximately 39 inches) foam plank block maintains tight firestop seal to prevent fire, smoke and toxic gas transmission
- Fits medium to large openings in wall and floor through-penetrations
- No cure time means faster completion
- Block is paintable with primer
- Pre-formed foam 1 meter (approximately 39 inches) foam plank block maintains tight firestop seal to prevent fire, smoke and toxic gas transmission
- Fits medium to large openings in wall and floor through-penetrations
- No cure time means faster completion
- Block is paintable with primer
- UPC
- 076308982317
- UNSPSC
- 46191507
- Country of Origin
- DEU
615+48-3M
$483.30 /ea
Thin, lightweight and flexible, 3M™ Fire Barrier Duct Wrap 615+ provides excellent insulating capabilities and offers a space-saving alternative to traditional bulky fire protection methods obtained through a gypsum wall shaft or enclosure. This wrap is commonly used in commercial kitchen grease ducts, as well as ventilation ducts.
| Attributed Data | Included |
|---|---|
| Fire Rating | 2 Hour Yes |
| Type | Fire Barrier Duct Wrap Yes |
PLENUM-WRAP-5A+(24")
$304.62 /ea
3M™ Fire Barrier Plenum Wrap 5A+ is a fire-resistant wrap that consists of an inorganic fiber blanket encapsulated with a scrim-reinforced foil. We designed this plenum wrap as a strong, lightweight and flexible material for easy installation. This product is engineered to create a fire-resistive enclosure that can reduce flame and smoke spread ratings to acceptable levels in return air plenums.
PLENUM-WRAP-5A+(48")
$324.93 /ea
3M™ Fire Barrier Plenum Wrap 5A+ is a fire-resistant wrap that consists of an inorganic fiber blanket encapsulated with a scrim-reinforced foil. We designed this plenum wrap as a strong, lightweight and flexible material for easy installation. This product is engineered to create a fire-resistive enclosure that can reduce flame and smoke spread ratings to acceptable levels in return air plenums.
| Attributed Data | Included |
|---|---|
| Color | White Yes |
| Shape | Roll Yes |
| Standard | ASTM NFPA UL ASTM Yes |
| Type | Fire Barrier Yes |
| Product Image |
|
|
|
|---|---|---|---|
|
615+48-3M
Thin, lightweight and flexible, 3M™ Fire Barrier Duct Wrap 615+ provides excellent insulating capabilities and offers a space-saving alternative to traditional bulky fire protection methods obtained through a gypsum wall shaft or enclosure. This wrap...
$483.30 / EA
|
PLENUM-WRAP-5A+(24")
3M™ Fire Barrier Plenum Wrap 5A+ is a fire-resistant wrap that consists of an inorganic fiber blanket encapsulated with a scrim-reinforced foil. We designed this plenum wrap as a strong, lightweight and flexible material for easy installation. This p...
$304.62 / EA
|
PLENUM-WRAP-5A+(48")
3M™ Fire Barrier Plenum Wrap 5A+ is a fire-resistant wrap that consists of an inorganic fiber blanket encapsulated with a scrim-reinforced foil. We designed this plenum wrap as a strong, lightweight and flexible material for easy installation. This p...
$324.93 / EA
|
|
| Attributed Data | |||
| Color | White White | ||
| Fire Rating | 2 Hour 2 Hour | ||
| Shape | Roll Roll | ||
| Standard | ASTM NFPA UL ASTM ASTM NFPA UL ASTM | ||
| Type | Fire Barrier Fire Barrier | Fire Barrier Duct Wrap Fire Barrier Duct Wrap | |
| Add a product to the cart | Show more details | Show more details | Show more details |
