$39.96 / EA
In stock (0)
Lead time: over 7 days
may be longer on small orders
Eaton Bussmann series REN fuse, Renewable fuse, Super lag, time lag, non current-limiting, Industrial and commercial structures, 20 A, Class H, Non-indicating, Ferrule end x ferrule end, 10 kAIC, Standard, 10, 250 V
Eaton Bussmann series REN fuse, Renewable fuse, Super lag, time lag, non current-limiting, Industrial and commercial structures, 20 A, Class H, Non-indicating, Ferrule end x ferrule end, 10 kAIC, Standard, 10, 250 V
Non-current limiting, renewable 250V (REN) and 600V (RES) Class H size fuses and fuse links (250V LK...150
Non-current limiting, renewable 250V (REN) and 600V (RES) Class H size fuses and fuse links (250V LKN and 600V LKS) for use in electrical systems where the available fault current is less than 10,000 amps and frequent outages dictate the economy of these renewable type fuses.
- UPC
- 051712100205
- UNSPSC
- 39121605
- Country of Origin
- MX
- Amperage Rating:
- 20 A
- Size:
- 0.56 In Diameter X 2.00 In Length
- Type:
- Fuse
- Voltage Rating:
- 250 V
- Amperage Rating:
- 20 A
- Class:
- H
- Connection:
- Ferrule end x ferrule end
- Dimensions:
- 0.5600 IN X 0.5600 IN X 2.0000 IN
- Interrupt Rating:
- 10 kAIC
- Size:
- 0.56 In Diameter X 2.00 In Length
- Standard:
- Not Applicable,RoHS Compliant
- Sub Brand:
- Bussmann Series
- Type:
- Fuse
- Voltage Rating:
- 250 V
S-1-6/10
$21.41 /ea
Eaton Bussmann series Type S plug fuse, plug fuse, time delay, heavy duty, packaging type blister pack, 1-6/10 A, 125 Vac, 10 kAIC (RMS Symmetrical) interrupt rating, 10 kA short circuit rating, threaded mount, duel element, plastic base
| Attributed Data | Included |
|---|---|
| Amperage Rating | 1-6/10A Yes |
| Dimensions | 12.8800 IN X 6.7500 IN X 12.5600 IN Yes |
| Element | Dual Yes |
| Interrupt Rating | 10 kAIC Yes |
| Material | Plastic Yes |
| Mounting | Threaded Yes |
| Standard | Contact factory Yes |
| Sub Brand | Bussmann Series Yes |
| Type | Plug fuse Yes |
T-8/10
$21.24 /ea
Eaton Bussmann series Type T plug fuse, plug fuse, time delay, heavy duty, 8/10 A, 125 Vac, 10 kAIC (RMS Symmetrical) interrupt rating, 10 kA short circuit rating, threaded mount, duel element, plastic body, brass thread, edison base
| Attributed Data | Included |
|---|---|
| Amperage Rating | 8/10A Yes |
| Dimensions | 12.8800 IN X 6.7500 IN X 12.5600 IN Yes |
| Interrupt Rating | 10 kAIC Yes |
| Standard | Contact factory Yes |
| Sub Brand | Bussmann Series Yes |
| Type | Plug fuse Yes |
S-3
$20.15 /ea
Eaton Bussmann series Type S plug fuse, plug fuse, time delay, heavy duty, packaging type blister pack, 3 A, 125 Vac, 10 kAIC (RMS Symmetrical) interrupt rating, 10 kA short circuit rating, threaded mount, plastic base, rejection base
| Attributed Data | Included |
|---|---|
| Dimensions | 12.8800 IN X 6.7500 IN X 12.5600 IN Yes |
| Element | Dual Yes |
| Interrupt Rating | 10 kAIC Yes |
| Material | Plastic Yes |
| Mounting | Threaded Yes |
| Standard | Contact factory Yes |
| Sub Brand | Bussmann Series Yes |
| Type | Plug fuse Yes |
| Product Image |
|
|
|
|---|---|---|---|
|
S-1-6/10
Eaton Bussmann series Type S plug fuse, plug fuse, time delay, heavy duty, packaging type blister pack, 1-6/10 A, 125 Vac, 10 kAIC (RMS Symmetrical) interrupt rating, 10 kA short circuit rating, threaded mount, duel element, plastic base
$21.41 / EA
|
T-8/10
Eaton Bussmann series Type T plug fuse, plug fuse, time delay, heavy duty, 8/10 A, 125 Vac, 10 kAIC (RMS Symmetrical) interrupt rating, 10 kA short circuit rating, threaded mount, duel element, plastic body, brass thread, edison base
$21.24 / EA
|
S-3
Eaton Bussmann series Type S plug fuse, plug fuse, time delay, heavy duty, packaging type blister pack, 3 A, 125 Vac, 10 kAIC (RMS Symmetrical) interrupt rating, 10 kA short circuit rating, threaded mount, plastic base, rejection base
$20.15 / EA
|
|
| Attributed Data | |||
| Amperage Rating | 1-6/10A 1-6/10A | 3 A 3 A | 8/10A 8/10A |
| Dimensions | 12.8800 IN X 6.7500 IN X 12.5600 IN 12.8800 IN X 6.7500 IN X 12.5600 IN | ||
| Element | Dual Dual | ||
| Interrupt Rating | 10 kAIC 10 kAIC | ||
| Material | Plastic Plastic | ||
| Mounting | Threaded Threaded | ||
| Standard | Contact factory Contact factory | ||
| Sub Brand | Bussmann Series Bussmann Series | ||
| Type | Plug fuse Plug fuse | ||
| Type Of Indicators | Non-Indicating Non-Indicating | ||
| Voltage Rating | 125 V 125 V | ||
| Add a product to the cart | Show more details | Show more details | Show more details |
