$0.08 / EA
Local stock: 0
Lead time:
over 7 working days
Blue Fluted Body Wire Connectors Joins #22 - #14 AWG 100/Box
Blue Fluted Body Wire Connectors Joins #22 - #14 AWG 100/Box
The fluted body design of Topaz�s Wire Connectors improves performance and the positive grip design...150
The fluted body design of Topaz�s Wire Connectors improves performance and the positive grip design enables fast and easy installation. All models help secure important solid or stranded conductor configurations in your devices and are color coded for simple size and capacity identification; fabricated from durable polypropylene and engineered to withstand temperatures up to 105� C. Square wire spring insert ensures secure, long lasting connections; gray color coded models joins # 22 through # 14 AWG. UL listed for 600V.
- Easy installation
- Flame retardant; temperature rating of 105�C
- Color coded for easy size and capacity identification
- Square wire spring insert for secure connections
- Easy installation
- Flame retardant; temperature rating of 105�C
- Color coded for easy size and capacity identification
- Square wire spring insert for secure connections
- UPC
- 751338305403
- UNSPSC
- 39121409
- Country of Origin
- MUL
- Color:
- Blue
- Material:
- Polypropylene
- Type:
- Fluted Wire Connector
- Voltage Rating:
- 300 V
- Color:
- Blue
- Conductor Range:
- 18/2 to 16/3 AWG
- ISTMT (testing temp) (DEG C):
- +105 DEG C
- Label Description:
- WIRE CONNECTORS
- Material:
- Polypropylene
- Max Number of Conductors:
- 2, 3
- Number Of Conductors:
- 2, 3
- Standard:
- UL 467, UL File Number E155861, US Federal Specification Number A-A-50552, NEMA/ANSI FB-1, CSA Certified, Military Specification:W-F-406D, W-F-406E, W-F-408D, W-S-610D
- Temperature Rating:
- +105 DEG C
- Type:
- Fluted Wire Connector
- Voltage (V):
- 300 V
- Voltage Rating:
- 300 V
- Wire Size:
- 22 to 14 AWG AWG
