WMT22AB225J
SKU: WMT22AB225J
MPN: WMT22AB225J
Key specs
View all- Amperage Rating
- 225 A
- Size
- 2
- Type
- WMTCOMMERCIALMETERSTACK
- Voltage Rating
- 120 V
Description
Product overview
Siemens Low Voltage s Multi-Family Metering Line of Power Mod Test Block BypassMeter Stacks as part of the Power Mod Commercial Meter Stacks Group. Type POWERMOD Features TEST BLOCK BYPASS, EXTRA JAW Appn GARDEN - STYLE, METER RISE, HIGHRISE Std UL-67 V. Rating 120/208VAC A. Rating 225A Phase 3PH IN/1PH OUT Size 46.000x21.500x9.000 No. Of Cutouts 4 Cutout Size 1,1-1/4,1-1/2,1-3/4,2 Cable EntryBOTTOM FEED Terminal QUICK CONNECT. Insulated. Mounting rails. Enclosure TYPE 3R
Siemens Low Voltage s Multi-Family Metering Line of Power Mod Test Block BypassMeter Stacks as part of the Power Mod Commercial Meter Stacks Group. Type POWERMOD Features TEST BLOCK BYPASS, EXTRA JAW Appn GARDEN - STYLE, METER RISE, HIGHRISE Std UL-67 V. Rating 120/208VAC A. Rating 225A Phase 3PH IN/1PH OUT Size 46.000x21.500x9.000 No. Of Cutouts 4 Cutout Size 1,1-1/4,1-1/2,1-3/4,2 Cable EntryBOTTOM FEED Terminal QUICK CONNECT. Insulated. Mounting rails. Enclosure TYPE 3R
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A WMT22AB225J POWMOD WMT 2G 5J 3P
- Invoice description
- POWMOD WMT 2G 5J 3PH IN 225A AC/BC
Specifications
- UPC
- 040892171303
- UNSPSC
- 39121102
- Country of Origin
- US
- Amperage Rating
- 225 A
- Size
- 2
- Type
- WMTCOMMERCIALMETERSTACK
- Voltage Rating
- 120 V
- Amperage Rating
- 225 A
- Cable Entry
- THRU-BUS
- Depth [in]
- 9 in
- Frequency Rating
- TRUE
- Mounting
- SURFACE/SIEMENSQuickRoll
- Number of terminals
- 3
- Phase
- 1
- Size
- 2
- Special product feature
- TESTBLOCKBYPASS
- Standard
- UL67
- Sub Brand
- POWERMOD
- Terminal
- 5-JAW
- Type
- WMTCOMMERCIALMETERSTACK
- Voltage / between phase and phase / rated value
- 208 V
- Voltage Rating
- 120 V
- Width [in]
- 21.5 in
