XAL-458
SKU: XAL-458
MPN: XAL-458
Key specs
View all- Action
- SP
- Amperage Rating
- 2.5/10 A
- Number Of Poles
- 1
- Size
- 5-1/4" H x 3-5/8" W x 5-13/64" D
- Type
- Aluminum fire alarm station with pull-ring activation
- Voltage Rating
- 600 VAC
Description
Product overview
XAL SERIES - ALUMINUM FEED-THRU FIRE ALARM STATION WITH PULL-RINGACTIVATION - HUB SIZE 3/4 INCH - 2NO/2NC CONTACT RATING
XAL SERIES - ALUMINUM FEED-THRU FIRE ALARM STATION WITH PULL-RINGACTIVATION - HUB SIZE 3/4 INCH - 2NO/2NC CONTACT RATING
Manufacturer highlights
Additional manufacturer notes
- Short name
- KLRK
- Feed description
- KLRK XAL-458 FIRE ALARM 2NO 2NC
- Invoice description
- FIRE ALARM 2NO 2NC CONTACTS
Specifications
- UPC
- 783936880402
- UNSPSC
- 39122216
- Country of Origin
- US
- Action
- SP
- Amperage Rating
- 2.5/10 A
- Number Of Poles
- 1
- Size
- 5-1/4" H x 3-5/8" W x 5-13/64" D
- Type
- Aluminum fire alarm station with pull-ring activation
- Voltage Rating
- 600 VAC
- Action
- SP
- Actuator
- Pull ring
- Amperage Rating
- 2.5/10 A
- Contact Configuration
- 2-NO/2-NC
- Contact Rating
- 7200 VA (make), 720 VA (break), 10A cont. @ 600V AC; 2.5A cont. @ 600V DC.
- Enclosure
- Aluminum enclosure
- Environmental Conditions
- Hazardous locations
- Number Of Poles
- 1
- Size
- 5-1/4" H x 3-5/8" W x 5-13/64" D
- Standard
- UL, ULC,CSA
- Type
- Aluminum fire alarm station with pull-ring activation
- Voltage Rating
- 600 VAC
