$14.86 / EA
manufacturer discounts
learn about discounts
- $13.33 for $1,500.00+
- $12.81 for $2,500.00+
- $12.30 for $3,500.00+
In stock (0)
Lead time: over 7 days
may be longer on small orders
FUSE LINK, SITOR, 5A, 660V AC, 14 X 51MM SITOR CYLINDRICAL FUSE LINK AR 5 A, 660 V AC/700 V DC
FUSE LINK, SITOR, 5A, 660V AC, 14 X 51MM SITOR CYLINDRICAL FUSE LINK AR 5 A, 660 V AC/700 V DC
150
- UPC
- 662643167566
- UNSPSC
- 39121626
- Country of Origin
- DE
- Amperage Rating:
- 5 A
- Size:
- NH1
- Type:
- Semiconductor Fuses SITOR
- Voltage Rating:
- 660 V
- Amperage Rating:
- 5 A
- Current / at AC / rated value:
- 5
- Design of the product:
- DCacc.toUL
- Measurable line frequency / Full-scale value:
- 45
- Measurable line frequency / initial value:
- 62
- Net weight:
- 22.0g
- Operating class of the fuse link:
- aR
- Operating current / Rated value:
- 5
- Operating voltage / rated value:
- 690
- Power loss [W] / for rated value of the current / at AC / in hot operating state / per pole:
- 1.5
- Power loss [W] / maximum:
- 1.5
- Product component / striker:
- No
- Product designation:
- SITORcylindricalfuselink
- Reference code / acc. to DIN EN 61346-2:
- F
- Reference code / acc. to DIN EN 81346-2:
- F
- Size:
- NH1
- Size of the fuse link:
- 14x51mm
- Standard:
- UL 512
- Sub Brand:
- SENTRON
- Supply voltage / at DC:
- 700
- Supply voltage / rated value / maximum:
- 690V
- Supply voltage / rated value / minimum:
- 10V
- Switching capacity short-circuit current:
- 100kA
- Tripping characteristic class:
- aR
- Type:
- Semiconductor Fuses SITOR
- Type of voltage:
- AC
- Voltage Rating:
- 660 V
- mounting position:
- Any,preferablyvertical
- product brand name:
- SENTRON
MV055F1CAX40E-EDF
$1,239.09 /ea
Eaton Bussmann series MV055 E-Rated medium voltage fuse, 5.5 kV, 40A, 50 kAIC, Non Indicating, Current limiting, Ferrule end X ferrule end, Class E, Fiberglass tube, 1 - MV055F1CAX40E
Attributed Data | Included |
---|---|
Class | Class E Yes |
Connection | Ferrule end x ferrule end Yes |
Dimensions | 2.0000 IN X 2.0000 IN X 15.7500 IN Yes |
Element | Silver ribbon Yes |
Interrupt Rating | 50 kAIC Yes |
Material | Fiberglass Yes |
Standard | ANSI,Contact factory Yes |
Sub Brand | Bussmann Series Yes |
Type | Fuse Yes |
UHT-MY
$264.11 /ea
Eaton Bussmann series UHT cable limiter, MY
Attributed Data | Included |
---|---|
Dimensions | 0.9700 IN X 1.1000 IN X 4.3000 IN Yes |
Standard | RoHS Compliant Yes |
Sub Brand | Bussmann Series Yes |
Type | Cable limiter Yes |
24OEGMA6.3
$519.41 /ea
Oil fuse-link, medium voltage, 6.3 A, AC 24 kV, BS2692 F02, 359 x 63.5 mm, back-up, BS, IEC, ESI, with striker
Attributed Data | Included |
---|---|
Class | Class back-up Yes |
Dimensions | 14.1339 IN X 2.6772 IN X 2.6772 IN Yes |
Interrupt Rating | 25 kAIC Yes |
Standard | IEC Rated,Contact factory Yes |
Sub Brand | Bussmann Series Yes |
Type | Medium voltage oil fuse Yes |
Product Image | |||
---|---|---|---|
MV055F1CAX40E-EDF
Eaton Bussmann series MV055 E-Rated medium voltage fuse, 5.5 kV, 40A, 50 kAIC, Non Indicating, Current limiting, Ferrule end X ferrule end, Class E, Fiberglass tube, 1 - MV055F1CAX40E
$1,239.09 / EA
|
UHT-MY
Eaton Bussmann series UHT cable limiter, MY
$264.11 / EA
|
24OEGMA6.3
Oil fuse-link, medium voltage, 6.3 A, AC 24 kV, BS2692 F02, 359 x 63.5 mm, back-up, BS, IEC, ESI, with striker
$519.41 / EA
|
|
Attributed Data | |||
Amperage Rating | 6.3 A 6.3 A | 40 A 40 A | |
Class | Class E Class E | Class back-up Class back-up | |
Connection | Ferrule end x ferrule end Ferrule end x ferrule end | ||
Dimensions | 0.9700 IN X 1.1000 IN X 4.3000 IN 0.9700 IN X 1.1000 IN X 4.3000 IN | 2.0000 IN X 2.0000 IN X 15.7500 IN 2.0000 IN X 2.0000 IN X 15.7500 IN | 14.1339 IN X 2.6772 IN X 2.6772 IN 14.1339 IN X 2.6772 IN X 2.6772 IN |
Element | Silver ribbon Silver ribbon | ||
Interrupt Rating | 25 kAIC 25 kAIC | 50 kAIC 50 kAIC | |
Material | Fiberglass Fiberglass | ||
Standard | ANSI,Contact factory ANSI,Contact factory | IEC Rated,Contact factory IEC Rated,Contact factory | RoHS Compliant RoHS Compliant |
Sub Brand | Bussmann Series Bussmann Series | ||
Type | Cable limiter Cable limiter | Fuse Fuse | Medium voltage oil fuse Medium voltage oil fuse |
Voltage Rating | 5,500 V 5,500 V | 24,000 V 24,000 V | |
