$102.95 / EA
manufacturer discounts
learn about discounts
- $92.30 for $1,500.00+
- $88.75 for $2,500.00+
- $85.20 for $3,500.00+
In stock (0)
Lead time: over 7 days
may be longer on small orders
FUSE LINK CLASS CC 5A FUSE LINK CLASS CC ACC. TO UL STANDARD 248-4 SLOW-BLOW RATED CURRENT 5 A RATED VOLTAGE UP TO 600 V AC SIZE 10.3 MM X 38.1 MM
FUSE LINK CLASS CC 5A FUSE LINK CLASS CC ACC. TO UL STANDARD 248-4 SLOW-BLOW RATED CURRENT 5 A RATED VOLTAGE UP TO 600 V AC SIZE 10.3 MM X 38.1 MM
150
- UPC
- 754554944968
- UNSPSC
- 39121626
- Country of Origin
- DE
- Amperage Rating:
- 5 A
- Material:
- Ceramic/Plastic
- Size:
- NH0
- Type:
- Fuse Link
- Voltage Rating:
- 600 V
- Amperage Rating:
- 5 A
- Current / at AC / rated value:
- 5
- Material:
- Ceramic/Plastic
- Measurable line frequency / Full-scale value:
- 50
- Measurable line frequency / initial value:
- 60
- Net weight:
- 9.0g
- Operating class of the fuse link:
- Slow
- Operating current / Rated value:
- 5
- Operating voltage / rated value:
- 600
- Product component / striker:
- No
- Product designation:
- Cylindricalfuselink
- Reference code / acc. to DIN EN 61346-2:
- F
- Reference code / acc. to DIN EN 81346-2:
- F
- Size:
- NH0
- Size of the fuse link:
- ClassCC
- Standard:
- UL 248
- Sub Brand:
- SENTRON
- Supply voltage / rated value / maximum:
- 600V
- Supply voltage / rated value / minimum:
- 10V
- Switching capacity short-circuit current:
- 200kA
- Tripping characteristic class:
- Slow-response
- Type:
- Fuse Link
- Type of voltage:
- AC
- Voltage Rating:
- 600 V
- mounting position:
- Any,preferablyvertical
- product brand name:
- SENTRON
