SIEMENS LOW VOLTAGE 3VA UL MOLDED CASE CIRCUIT BREAKER WITH ELECTRONIC TRIP UNIT. 3VA61 FRAME WITH VERY HIGH (CLASS C) BREAKING CAPACITY. 40A 3-POLE (35KAIC AT600V) (100KAIC AT 480V). ETU350 TRIP UNIT LSI. SPECIAL FEATURES WITHOUT LUGS 100 PERCENT RATED. DIMENSIONS (W x H x D) IN 4.1 x 7.8 x 4.2.

Image colors may not be accurate.
Please see details, or call (800) 462-7733 for more information.

3VA6140-7HN31-2AA0

$2,382.93 / EA

manufacturer discounts
learn about discounts

  • $2,136.42 for $1,500.00+
  • $2,054.25 for $2,500.00+
  • $1,972.08 for $3,500.00+

In stock (0)
Lead time: over 7 days
may be longer on small orders

SIEMENS LOW VOLTAGE 3VA UL MOLDED CASE CIRCUIT BREAKER WITH ELECTRONIC TRIP UNIT. 3VA61 FRAME WITH VERY HIGH (CLASS C) BREAKING CAPACITY. 40A 3-POLE (35KAIC AT600V) (100KAIC AT 480V). ETU350 TRIP UNIT LSI. SPECIAL FEATURES WITHOUT LUGS 100 PERCENT RATED. DIMENSIONS (W x H x D) IN 4.1 x 7.8 x 4.2.

SIEMENS LOW VOLTAGE 3VA UL MOLDED CASE CIRCUIT BREAKER WITH ELECTRONIC TRIP UNIT. 3VA61 FRAME WITH VERY HIGH (CLASS C) BREAKING CAPACITY. 40A 3-POLE (35KAIC AT600V) (100KAIC AT 480V). ETU350 TRIP UNIT LSI. SPECIAL FEATURES WITHOUT LUGS 100 PERCENT RATED. DIMENSIONS (W x H x D) IN 4.1 x 7.8 x 4.2.

150

UPC
804766303463
UNSPSC
39121601
Country of Origin
CZ
Number Of Poles:
3
Type:
3VA6
Voltage Rating:
480 V
Adjustable delay time / of S-trip / with I2t characteristic / Full-scale value:
0.40s
Adjustable delay time / of S-trip / with I2t characteristic / initial value:
0.02s
Adjustable pick-up value current / of instantaneous short-circuit trip unit / Full-scale value:
480
Adjustable pick-up value current / of instantaneous short-circuit trip unit / initial value:
480
Adjustable pick-up value current / of the current-dependent overload release / Full-scale value:
40
Adjustable pick-up value current / of the short-time delayed short-circuit release / Full-scale value:
400.00A
Adjustable pick-up value current / of the short-time delayed short-circuit release / initial value:
60.00A
Ambient temperature / during storage / maximum:
80
Arrangement of electrical connectors / for main current circuit:
Withoutconnection
Connection:
punched copper bar without any lug
Current Rating:
40A
Frame:
150A
Height:
7.8 in
Interrupt Rating:
WITH 100kA INTERRUPTION RATING
Length:
4.13
Maximum short-circuit current breaking capacity (Icu) / at 240 V / rated value:
150
Maximum short-circuit current breaking capacity (Icu) / at 415 V / rated value:
110
Mounting type:
fixedmounting
Number Of Poles:
3
Operational short-circuit current breaking capacity (Ics) / at 240 V / rated value:
150kA
Operational short-circuit current breaking capacity (Ics) / at 690 V / rated value:
2.5
Product variations:
Advancedapplications
Protection class IP:
IP40
Protection class IP / on the front:
IP40
Reference code / acc. to DIN EN 61346-2:
Q
Setting range / Overload function L / IR can be switched on:
No
Standard:
UL
Sub Brand:
3VA
Trip Type:
ETU350 LSI ADJUSTMENT KNOB
Type:
3VA6
Type of electrical connection / for main current circuit:
Without
Voltage Rating:
480 V
Width:
4.21
