3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages up to 15kV.
3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages up to 15kV.

Image colors may not be accurate.
Please see details, or call (800) 462-7733 for more information.

5644

Manufacturer
3M

$276.82 / EA

Available to order

Local stock: 0
Lead time: over 7 working days

3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages up to 15kV.

3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages up to 15kV.

150

  • One-piece cold shrink termination.
  • High dielectric-constant material regulates the distribution of electric field stress
  • Suitable for outdoor, weather exposed applications
  • Silicone rubber insulation is track-resistance and hydrophobic
  • One-piece cold shrink termination.
  • High dielectric-constant material regulates the distribution of electric field stress
  • Suitable for outdoor, weather exposed applications
  • Silicone rubber insulation is track-resistance and hydrophobic
UPC
054007119739
UNSPSC
26121648
Country of Origin
USA
Type:
QT-II
Voltage Rating:
15,000 V
BIL:
110 kV
Cable Insulation Outside Diameter Range:
1.31-2.10 in
Cable Type:
Jacketed Concentric Neutral (JCN)
Conductor Size:
1000 kcmil; 1250 kcmil; 1500 kcmil; 750 kcmil; 800 kcmil; 900 kcmil
Insulation Level:
100%; 133%
Lug/Stem Connector Included in Kit:
No
Maximum Installed Length:
11.25 in
Number Of Terminals:
1
Number of Skirts:
4
Standard:
IEEE
Type:
QT-II
Voltage Rating:
15,000 V
