$21.16 / EA
Local stock: 0
Lead time:
over 7 working days
3M™ Cold Shrink QT II 5600 & 5680 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for concentric neutral cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages of 5 to 15kV.
3M™ Cold Shrink QT II 5600 & 5680 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for concentric neutral cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages of 5 to 15kV.
150
- One-piece cold shrink termination.
- High dielectric-constant material regulates the distribution of electric field stress
- Suitable for outdoor, weather exposed applications
- Silicone rubber insulation is track-resistance and hydrophobic
- One-piece cold shrink termination.
- High dielectric-constant material regulates the distribution of electric field stress
- Suitable for outdoor, weather exposed applications
- Silicone rubber insulation is track-resistance and hydrophobic
- UPC
- 054007697947
- UNSPSC
- 26121648
- Country of Origin
- USA
- Type:
- QT-II
- Voltage Rating:
- 892.857/5,000/8,000/15,000 V
- BIL:
- 150 kV
- Cable Insulation Outside Diameter Range:
- 0.84-1.38 in
- Cable Type:
- Concentric Neutral (CN); Jacketed Concentric Neutral (JCN)
- Conductor Size:
- 1 AWG; 1/0 AWG; 2/0 AWG; 250 kcmil; 3/0 AWG; 300 kcmil; 350 kcmil; 4/0 AWG; 400 kcmil; 500 kcmil; 600 kcmil; 750 kcmil
- Lug/Stem Connector Included in Kit:
- No
- Maximum Installed Length:
- 11.50 in
- Number Of Terminals:
- 1
- Number of Skirts:
- 6
- Standard:
- IEEE
- Type:
- QT-II
- Voltage Rating:
- 892.857/5,000/8,000/15,000 V
