5741
SKU: 5741-3M
MPN: 5741
Key specs
View all- Type
- Inline Splice
- Voltage Rating
- 625 V
Description
Product overview
The 3M™ Cold Shrink Splicing Products are designed using the proprietary cold shrink delivery system developed by 3M. Products are supplied prestretched on a removable core for efficiency and ease of installation. 3M™ Cold Shrink Splices 5740 Series are used for single conductor, non-shielded 5/8 kV cables.Each kit is a cold shrink design and contains enough material to insulate three splices. Connectors are not included and must be ordered separately.Note: Cable sizes shown below are for standa...
The 3M™ Cold Shrink Splicing Products are designed using the proprietary cold shrink delivery system developed by 3M. Products are supplied prestretched on a removable core for efficiency and ease of installation. 3M™ Cold Shrink Splices 5740 Series are used for single conductor, non-shielded 5/8 kV cables.Each kit is a cold shrink design and contains enough material to insulate three splices. Connectors are not included and must be ordered separately.Note: Cable sizes shown below are for standard insulation thickness. Final determining factor is cable insulation O.D.
Manufacturer highlights
- Designed for use with 10000, 11000 and 20000 Series inline compression connectors
- The rubber mastic filler removes time-consuming penciling of cable insulation
- Perfect for splicing non-shielded, wet/dry solid dielectric power cables
- Rated for 5/8 kV applications
Additional manufacturer notes
- Short name
- 3M
- Feed description
- 3M 5741 KIT, 5741
- Label description
- 3M(TM) Inline Splicing Kit for Non-Shielded 5/8 kV Cable 5741, 8-4 AWG, Cable Insulation O.D. 0.38-0.70, 1 per case
- Invoice description
- KIT, 5741
Specifications
- UPC
- 054007494911
- UNSPSC
- 39121718
- Country of Origin
- USA
- Type
- Inline Splice
- Voltage Rating
- 625 V
- Cable Size
- 4 AWG; 6 AWG; 8 AWG
- Number Of Cables
- 1
- Type
- Inline Splice
- Voltage Rating
- 625 V
