5SJ4135-7HG42
SKU: 5SJ4135-7HG42
MPN: 5SJ4135-7HG42
Key specs
View all- Number Of Poles
- 1
- Type
- NSJ
- Voltage Rating
- 277/480 V
Description
Product overview
CIRCUIT BREAKER 10KA, 1POLE, C, 35A ACC. TO UL 489 - 277V
CIRCUIT BREAKER 10KA, 1POLE, C, 35A ACC. TO UL 489 - 277V
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A 5SJ4135-7HG42 MCB 5SJ4 1P 277V
- Invoice description
- MCB 5SJ4 1P 277V 35A 10K C-TRIP
Specifications
- UPC
- 754554959351
- UNSPSC
- 39121601
- Country of Origin
- DE
- Number Of Poles
- 1
- Type
- NSJ
- Voltage Rating
- 277/480 V
- Class
- D
- Connectable conductor cross-section / finely stranded / with core end processing / maximum
- 25m
- Connectable conductor cross-section / finely stranded / with core end processing / minimum
- 1.50m
- Connection
- Identical wire screw connections on line and load side.
- Frequency Rating
- 50 Hz
- Height
- 121
- Installation environment regarding EMC
- SuitableforenvironmentB(immunitytointerferencenotapplicable)
- Insulation voltage / at AC / rated value
- 440V
- Interrupt Rating
- 10kA
- Mounting
- On standard mounting rail (DIN 35mm)
- Number Of Poles
- 1
- Number of test cycles / for environmental testing / acc. to IEC 60068-2-30
- 6
- Operating voltage / at DC / 1-channel / acc. to UL 489 and CSA C22.2 No. 5-02 / maximum
- 60V
- Operating voltage / at DC / 2-channel / acc. to UL 489 and CSA C22.2 No. 5-02 / maximum
- 125V
- Overvoltage category
- 3
- Power loss [W] / for rated value of the current / at AC / in hot operating state / per pole
- 3.4
- Power loss [W] / maximum
- 2.2
- Product component / Tunnel terminals bottom
- No
- Product component / Tunnel terminals top
- No
- Product component / combined terminal bottom
- Yes
- Product component / combined terminal top
- Yes
- Product feature / Touch protection
- Yes
- Product feature / halogen-free
- Yes
- Product feature / silicon-free
- Yes
- Product function / Note
- TerminaltighteningtorqueforCu,60/75°C;3.5Nm/31lb.in
- Short Circuit Rating
- 10kA
- Standard
- UL 489 Rated
- Sub Brand
- SENTRON
- Type
- NSJ
- Type of voltage supply / at AC / acc. to UL 489 and CSA C22.2 No. 5-02
- 480/277
- Vibration resistance
- 50m/s²at25to150Hzand60m/s²at35Hz(4sec)
- Vibration resistance / acc. to IEC 60068-2-6
- 50m/s²at25to150Hzand60m/s²at35Hz(4sec)
- Voltage Rating
- 277/480 V
- Width
- 18
