$129.63 / EA
manufacturer discounts
learn about discounts
- $116.22 for $1,500.00+
- $111.75 for $2,500.00+
- $107.28 for $3,500.00+
Local stock: 0
Lead time:
over 7 working days
MCB UL489 1-P 60A D-TRIP SAME PHASE ONLY MINIATURE CIRCUIT-BREAKER 240 V 10 KA,1-POLE, D, 60 A, D=70 MM TO UL 489, SAME POLARITY
MCB UL489 1-P 60A D-TRIP SAME PHASE ONLY MINIATURE CIRCUIT-BREAKER 240 V 10 KA,1-POLE, D, 60 A, D=70 MM TO UL 489, SAME POLARITY
150
- UPC
- 754554932781
- UNSPSC
- 39121601
- Country of Origin
- DE
- Number Of Poles:
- 1
- Type:
- NSJ
- Voltage Rating:
- 240 V
- Breaking capacity short-circuit current (Icn) / at AC / acc. to UL 1077 and CSA C22.2 No.235:
- 10kA
- Class:
- D
- Connection:
- Identical wire screw connections on line and load side.
- Degree of pollution:
- 3
- Frequency Rating:
- 50 Hz
- Height:
- 90
- Installation depth:
- 70
- Interrupt Rating:
- 10kA
- Mounting:
- On standard mounting rail (DIN 35mm)
- Mounting type:
- onstandardmountingrail
- Number Of Poles:
- 1
- Number of poles / Note:
- 1P
- Number of width units:
- 1
- Operating voltage / at DC / rated value / maximum:
- 60
- Operating voltage / minimum:
- 24
- Product extension / can be installed / supplementary devices:
- Yes
- Product feature / sealable:
- Yes
- Product function / neutral conductor switching:
- No
- Protection class IP:
- IP20,withconnectedconductors,IP40inthehandlerange
- Short Circuit Rating:
- 10kA
- Standard:
- UL 489 Rated
- Sub Brand:
- SENTRON
- Supply voltage / at AC / rated value:
- 400
- Supply voltage / with multi-phase operation / at AC / rated value:
- 400V
- Supply voltage / with single-phase operation / at AC / rated value:
- 230V
- Supply voltage frequency / rated value:
- 50
- Switching capacity current / acc. to EN 60898 / rated value:
- 10k
- Switching capacity current / acc. to IEC 60947-2 / rated value:
- 15kA
- Tripping characteristic class:
- D
- Type:
- NSJ
- Type of voltage:
- AC/DC
- Voltage Rating:
- 240 V
- Width:
- 18
- mounting position:
- any
