$297.50 / EA
manufacturer discounts
learn about discounts
- $266.72 for $1,500.00+
- $256.46 for $2,500.00+
- $246.20 for $3,500.00+
Local stock: 0
Lead time:
over 7 working days
SUPPLEMENTARY PROTECTOR,2P,100A,CURVE B Supplementary Protector, UL1077 Rated, IEC Mini Circuit Breaker, 2 Pole, 100 Amps, 480 VAC, Trip Characteristic Curve B, 54mm Width, 70mm Depth, UL File E116386 in Vol. 1 Sec. 4
SUPPLEMENTARY PROTECTOR,2P,100A,CURVE B Supplementary Protector, UL1077 Rated, IEC Mini Circuit Breaker, 2 Pole, 100 Amps, 480 VAC, Trip Characteristic Curve B, 54mm Width, 70mm Depth, UL File E116386 in Vol. 1 Sec. 4
150
- UPC
- 754554921730
- UNSPSC
- 39121601
- Country of Origin
- GR
- Number Of Poles:
- 2
- Type:
- Miniature Circuit Breaker
- Voltage Rating:
- 400 V
- Class:
- B
- Connectable conductor cross-section / finely stranded / with core end processing / maximum:
- 35m
- Connectable conductor cross-section / finely stranded / with core end processing / minimum:
- 25.00m
- Connectable conductor cross-section / stranded / maximum:
- 50m
- Connection:
- Identical wire screw connections on line and load side.
- Depth:
- 76
- Frequency Rating:
- 50 Hz
- Height:
- 90
- Insulation voltage / with multi-phase operation / at AC / Rated value:
- 440V
- Interrupt Rating:
- 10kA
- Mounting:
- On standard mounting rail (DIN 35mm)
- Net weight:
- 529.0g
- Number Of Poles:
- 2
- Number of test cycles / for environmental testing / acc. to IEC 60068-2-30:
- 6
- Power loss [W] / for rated value of the current / at AC / in hot operating state / per pole:
- 8
- Power loss [W] / maximum:
- 16
- Product component / Tunnel terminals bottom:
- Yes
- Product component / Tunnel terminals top:
- Yes
- Product component / combined terminal bottom:
- No
- Product component / combined terminal top:
- No
- Product feature / halogen-free:
- Yes
- Product feature / silicon-free:
- Yes
- Short Circuit Rating:
- 10kA
- Standard:
- UL 1077 and CSA 22.2 No. 235-M 89
- Sub Brand:
- SENTRON
- Supply voltage frequency / rated value / Note:
- 50/60Hz
- Tightening torque / for terminal connection / recommended / Note:
- 2.5
- Tightening torque / with screw-type terminals / maximum:
- 3.5
- Tightening torque / with screw-type terminals / minimum:
- 2.5
- Tightening torque [lbf·in] / with screw-type terminals / maximum:
- 31
- Tightening torque [lbf·in] / with screw-type terminals / minimum:
- 22.1
- Type:
- Miniature Circuit Breaker
- Voltage Rating:
- 400 V
- Width:
- 54
