5SP4392-7
SKU: 5SP4392-7
MPN: 5SP4392-7
Key specs
View all- Material
- N/A
- Number Of Poles
- 3
- Size
- N/A
- Type
- Miniature Circuit Breaker
- Voltage Rating
- 400 V
Description
Product overview
SUPPLEMENTARY PROTECTOR,3P,125A,CURVE C Supplementary Protector, UL1077 Rated, IEC Mini Circuit Breaker, 3 Pole, 125 Amps, 480 VAC, Trip Characteristic Curve C, 81mm Width, 70mm Depth, UL File E116386 in Vol. 1 Sec. 4
SUPPLEMENTARY PROTECTOR,3P,125A,CURVE C Supplementary Protector, UL1077 Rated, IEC Mini Circuit Breaker, 3 Pole, 125 Amps, 480 VAC, Trip Characteristic Curve C, 81mm Width, 70mm Depth, UL File E116386 in Vol. 1 Sec. 4
Manufacturer highlights
Additional manufacturer notes
- Short name
- S-A
- Feed description
- S-A 5SP4392-7 SUP PTOR 5SP4 3P 480V
- Invoice description
- SUP PTOR 5SP4 3P 480V 125A 5K C-TRIP
Specifications
- UPC
- 754554758626
- UNSPSC
- 39121601
- Country of Origin
- GR
- Material
- N/A
- Number Of Poles
- 3
- Size
- N/A
- Type
- Miniature Circuit Breaker
- Voltage Rating
- 400 V
- AWG number / as coded connectable conductor cross section / maximum
- 1
- AWG number / as coded connectable conductor cross section / minimum
- 3
- Adapter Rating
- N/A
- Class
- C
- Connectable conductor cross-section / finely stranded / with core end processing / maximum
- 35m
- Connectable conductor cross-section / finely stranded / with core end processing / minimum
- 25.00m
- Connectable conductor cross-section / solid / maximum
- 50m
- Connectable conductor cross-section / solid / minimum
- 25.00m
- Connectable conductor cross-section / stranded / maximum
- 50m
- Connectable conductor cross-section / stranded / minimum
- 25.00m
- Connection
- Identical wire screw connections on line and load side.
- Element
- N/A
- Frequency Rating
- 50 Hz
- Height
- 90
- Insulation voltage / at AC / rated value
- 440V
- Interrupt Rating
- 10kA
- Material
- N/A
- Mounting
- On standard mounting rail (DIN 35mm)
- Number Of Poles
- 3
- Overvoltage category
- 3
- Product component / Tunnel terminals bottom
- Yes
- Product component / Tunnel terminals top
- Yes
- Product feature / Touch protection
- Yes
- Response Time
- N/A
- Shock resistance / acc. to IEC 60068-2-27
- 150m/s²at11mshalf-sine
- Short Circuit Rating
- 10kA
- Size
- N/A
- Standard
- UL 1077 and CSA 22.2 No. 235-M 89
- Sub Brand
- SENTRON
- Tightening torque / with screw-type terminals / minimum
- 2.5
- Type
- Miniature Circuit Breaker
- Type Of Indicators
- N/A
- Voltage Rating
- 400 V
- Width
- 81
