$0.63 / EA
Local stock: 0
Lead time:
over 7 working days
3/4" Zinc Die Cast Set Screw Type Connector
3/4" Zinc Die Cast Set Screw Type Connector
Topaz EMT connectors with set screw type assembly provide secure concrete tight protection when tape...150
Topaz EMT connectors with set screw type assembly provide secure concrete tight protection when taped and are available in trade sizes from 1/2� to 4�. Applications include use in dry locations to bond EMT thin wall conduits to electrical boxes or enclosures; set screw connectors offer superior corrosion resistance. Model sizes 2-1/2� to 4� are suitable for both EMT and rigid conduit. Constructed of durable zinc die cast, efficient and long lasting; UL listed. NEMA/ANSI FB-1 compliant.
- Set screw type connectors and couplings
- Concrete tight when taped
- Assembled with a die cast locknut
- Connectors available with insulated throat
- Set screw type connectors
- Concrete tight when taped
- Assembled with a die cast locknut
- Set screw type connectors and couplings
- Concrete tight when taped
- Assembled with a die cast locknut
- Connectors available with insulated throat
- Set screw type connectors
- Concrete tight when taped
- Assembled with a die cast locknut
- UPC
- 751338163003
- UNSPSC
- 39121434
- Country of Origin
- MUL
- Material:
- Die Cast Zinc
- Size:
- 3/4 IN
- Type:
- Set Screw EMT Connector
- Connection:
- Threaded x Set Screw
- Connectors (IN):
- Threaded x Set Screw IN
- Diameter:
- 1.30 IN
- For Use With:
- Join EMT To Box or Enclosure
- Insulation:
- None
- Label Description:
- EMT CONNECTORS
- Length:
- 1.39 IN
- Material:
- Die Cast Zinc
- Size:
- 3/4 IN
- Size (IN):
- 3/4" IN
- Standard:
- UL 514B, UL File Number E18472, US Federal Specification Number A-A-50553, CSA Certified, NEMA/ANSI FB-1, Military Specification:W-F-406D, W-F-406E, W-F-408D, W-S-610D
- Thread Length:
- 0.400 IN
- Type:
- Set Screw EMT Connector
Recently Viewed
-
-
3RA29233DA2
SIEMENS INDUSTRY, INC.
WIRING MODULE TOP FOR CONTACTOR ASSEMBLY S0 WITHOUT SPACE BETWEEN CONTACTORS
