$1,485.64 / EA
In stock (0)
Lead time: over 7 days
may be longer on small orders
3M™ Cold Shrink QT III 7600 T 3W Series Termination Kit includes a non skirted, 3 phase termination. It ensures a pliable, tight seal for tape shield, wire shield and UniShield® power cables. The conjunction of high dielectric constant material and sealing compounds allows the termination to withstand voltages of 5 to 35kV.
3M™ Cold Shrink QT III 7600 T 3W Series Termination Kit includes a non skirted, 3 phase termination. It ensures a pliable, tight seal for tape shield, wire shield and UniShield® power cables. The conjunction of high dielectric constant material and sealing compounds allows the termination to withstand voltages of 5 to 35kV.
150
- Provides a void-free seal to tape shield, wire shield and UniShield® power cables
- High dielectric-constant material regulates the distribution of electric field stress
- Suitable for indoor applications and cabinet-mount installations
- Integrated design allows for easier installation in limited spaces, while sealing compounds provide constant radial pressure
- Provides a void-free seal to tape shield, wire shield and UniShield® power cables
- High dielectric-constant material regulates the distribution of electric field stress
- Suitable for indoor applications and cabinet-mount installations
- Integrated design allows for easier installation in limited spaces, while sealing compounds provide constant radial pressure
- UPC
- 054007047384
- UNSPSC
- 26121648
- Country of Origin
- USA
- Type:
- QT-III
- Voltage Rating:
- 5,000/8,000/15,000 V
- BIL:
- 110 kV
- Cable Insulation Outside Diameter Range:
- 0.92-1.18 in
- Cable Type:
- Tape Shield; UniShield(R); Wire Shield
- Conductor Size:
- 250 kcmil; 300 kcmil; 350 kcmil; 400 kcmil; 500 kcmil; 600 kcmil; 700 kcmil; 750 kcmil
- Lug/Stem Connector Included in Kit:
- No
- Maximum Installed Length:
- 12.00 in
- Number Of Terminals:
- 3
- Standard:
- AEIC; IEC; JIS
- Type:
- QT-III
- Voltage Rating:
- 5,000/8,000/15,000 V
5646-1/0
$347.46 /ea
3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages up to 15kV.
| Attributed Data | Included |
|---|---|
| Additional Kit Contents | (1) SC0010 Stem Connector Yes |
| BIL | 200 kV Yes |
| Cable Insulation Outside Diameter Range | 0.84-1.38 in Yes |
| Cable Type | Jacketed Concentric Neutral (JCN) Yes |
| Conductor Size | 1/0 AWG Yes |
| Insulation Level | 100%; 133% Yes |
| Lug/Stem Connector Included in Kit | Yes Yes |
| Maximum Installed Length | 17.50 in Yes |
| Number of Skirts | 8 Yes |
| Standard | IEEE Yes |
| Type | QT-II Yes |
5647-4/0
$430.05 /ea
3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber insulation allows the termination to withstand voltages up to 15kV.
| Attributed Data | Included |
|---|---|
| Additional Kit Contents | (1) SC0040 Stem Connector Yes |
| BIL | 200 kV Yes |
| Cable Insulation Outside Diameter Range | 1.08-1.80 in Yes |
| Cable Type | Jacketed Concentric Neutral (JCN) Yes |
| Conductor Size | 250 kcmil; 300 kcmil; 350 kcmil; 4/0 AWG; 400 kcmil; 450 kcmil; 500 kcmil; 600 kcmil; 700 kcmil Yes |
| Insulation Level | 100%; 133% Yes |
| Lug/Stem Connector Included in Kit | Yes Yes |
| Maximum Installed Length | 19.50 in Yes |
| Number of Skirts | 8 Yes |
| Standard | IEEE Yes |
| Type | QT-II Yes |
7685-S-8-3-RJS
$2,345.70 /ea
3M™ Cold Shrink QT III 7600 S 3RJS Series Termination Kit includes a skirted, 3 phase termination. It ensures a pliable, tight seal for tape shield, wire shield and UniShield® power cables. The conjunction of high dielectric constant material and sealing compounds allows the termination to withstand voltages of 5 to 35kV.
| Attributed Data | Included |
|---|---|
| BIL | 200 kV Yes |
| Cable Insulation Outside Diameter Range | 1.18-1.52 in Yes |
| Cable Type | Tape Shield; UniShield(R); Wire Shield Yes |
| Conductor Size | 1000 kcmil; 250 kcmil; 300 kcmil; 350 kcmil; 4/0 AWG; 400 kcmil; 500 kcmil; 600 kcmil; 700 kcmil; 750 kcmil; 800 kcmil; 900 kcmil Yes |
| Lug/Stem Connector Included in Kit | No Yes |
| Maximum Installed Length | 20.50 in Yes |
| Number Of Terminals | 3 Yes |
| Number of Skirts | 8 Yes |
| Type | QT-III Yes |
| Product Image |
|
|
|
|---|---|---|---|
|
5646-1/0
3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber...
$347.46 / EA
|
5647-4/0
3M™ Cold Shrink QT II 5640 & 5650 Series Termination Kit includes a 4 skirt, 1 piece termination. It ensures a pliable, tight seal for jacketed concentric neutral power cables. The conjunction of high dielectric constant material and silicone rubber...
$430.05 / EA
|
7685-S-8-3-RJS
3M™ Cold Shrink QT III 7600 S 3RJS Series Termination Kit includes a skirted, 3 phase termination. It ensures a pliable, tight seal for tape shield, wire shield and UniShield® power cables. The conjunction of high dielectric constant material and sea...
$2,345.70 / EA
|
|
| Attributed Data | |||
| Additional Kit Contents | (1) SC0010 Stem Connector (1) SC0010 Stem Connector | (1) SC0040 Stem Connector (1) SC0040 Stem Connector | |
| BIL | 200 kV 200 kV | ||
| Cable Insulation Outside Diameter Range | 0.84-1.38 in 0.84-1.38 in | 1.08-1.80 in 1.08-1.80 in | 1.18-1.52 in 1.18-1.52 in |
| Cable Type | Jacketed Concentric Neutral (JCN) Jacketed Concentric Neutral (JCN) | Tape Shield; UniShield(R); Wire Shield Tape Shield; UniShield(R); Wire Shield | |
| Conductor Size | 1/0 AWG 1/0 AWG | 250 kcmil; 300 kcmil; 350 kcmil; 4/0 AWG; 400 kcmil; 450 kcmil; 500 kcmil; 600 kcmil; 700 kcmil 250 kcmil; 300 kcmil; 350 kcmil; 4/0 AWG; 400 kcmil; 450 kcmil; 500 kcmil; 600 kcmil; 700 kcmil | 1000 kcmil; 250 kcmil; 300 kcmil; 350 kcmil; 4/0 AWG; 400 kcmil; 500 kcmil; 600 kcmil; 700 kcmil; 750 kcmil; 800 kcmil; 900 kcmil 1000 kcmil; 250 kcmil; 300 kcmil; 350 kcmil; 4/0 AWG; 400 kcmil; 500 kcmil; 600 kcmil; 700 kcmil; 750 kcmil; 800 kcmil; 900 kcmil |
| Insulation Level | 100%; 133% 100%; 133% | ||
| Lug/Stem Connector Included in Kit | No No | Yes Yes | |
| Maximum Installed Length | 17.50 in 17.50 in | 19.50 in 19.50 in | 20.50 in 20.50 in |
| Number Of Terminals | 1 1 | 3 3 | |
| Number of Skirts | 8 8 | ||
| Standard | IEEE IEEE | ||
| Type | QT-II QT-II | QT-III QT-III | |
| Voltage Rating | 892.857/5,000/8,000/15,000/35,000 V 892.857/5,000/8,000/15,000/35,000 V | 892.857/15,000/35,000 V 892.857/15,000/35,000 V | |
| Add a product to the cart | Show more details | Show more details | Show more details |
