$49.35 / EA
In stock (0)
Lead time: over 7 days
may be longer on small orders
Eaton Bussmann series FWP high speed fuse, 700 Vac (IEC), 700 Vdc (UL), 25A, 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end, Class aR, White, Ceramic
Eaton Bussmann series FWP high speed fuse, 700 Vac (IEC), 700 Vdc (UL), 25A, 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end, Class aR, White, Ceramic
Eaton�s Bussmann series High speed cylindrical fuses are suitable for the protection of AC and DC Dr...150
Eaton�s Bussmann series High speed cylindrical fuses are suitable for the protection of AC and DC Drives, power converters/ rectifiers and variable speed drives. They are available as gR and aR operating class
- UPC
- 051712796538
- UNSPSC
- 39121628
- Country of Origin
- IN
- Amperage Rating:
- 25 A
- Material:
- Ceramic
- Size:
- 0.875 In Diameter X 2.283 In Length
- Type:
- High speed cylindrical fuse
- Voltage Rating:
- 700 V
- Amperage Rating:
- 25 A
- Class:
- Class aR
- Connection:
- Ferrule end x ferrule end
- Dimensions:
- 2.2047 IN X 0.9055 IN X 0.9055 IN
- Height:
- 58 mm
- Interrupt Rating:
- 50 kAIC at 300 Vdc200 kAIC at 300 Vdc
- Length:
- 56 mm
- Material:
- Ceramic
- Size:
- 0.875 In Diameter X 2.283 In Length
- Standard:
- CSA Certified ,UL Recognized,CE Marked,RoHS Compliant
- Sub Brand:
- Bussmann Series
- Type:
- High speed cylindrical fuse
- Voltage Rating:
- 700 V
- Weight:
- 0.034 kg
- Width:
- 23 mm
KAW-30
$126.57 /ea
Eaton Bussmann series KAW semiconductor fuse, 30 A
| Attributed Data | Included |
|---|---|
| Dimensions | 0.3600 IN X 0.3600 IN X 1.5000 IN Yes |
| Standard | Contact factory,Contact Manufacturer Yes |
| Sub Brand | Bussmann Series Yes |
| Type | Semiconductor fuse Yes |
FWC-25A10F
$27.03 /ea
Eaton Bussmann series FWC high speed cylindrical fuse, 500 Vac/dc (35-800A only), 25A, 200 kAIC Vac, 50 kAIC at 700 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end
| Attributed Data | Included |
|---|---|
| Connection | Ferrule end x ferrule end Yes |
| Dimensions | 1.4961 IN X 0.4331 IN X 0.4331 IN Yes |
| Interrupt Rating | 50 kAIC at 700 Vdc200 kAIC Vac Yes |
| Size | 0.406 In Diameter X 1.500 In Length Yes |
| Standard | UL Recognized ,CSA Certified,CE Marked Yes |
| Sub Brand | Bussmann Series Yes |
| Type | High speed cylindrical fuse Yes |
FWC-32A10F
$27.03 /ea
Eaton Bussmann series FWC high speed cylindrical fuse, 600V (UL), 32A, 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end, Class aR, White, Ceramic
| Attributed Data | Included |
|---|---|
| Class | Class aR Yes |
| Connection | Ferrule end x ferrule end Yes |
| Dimensions | 1.4961 IN X 0.4331 IN X 0.4331 IN Yes |
| Interrupt Rating | 50 kAIC at 300 Vdc200 kAIC at 300 Vdc Yes |
| Material | Ceramic Yes |
| Size | 0.406 In Diameter X 1.500 In Length Yes |
| Standard | CSA Certified ,UL Recognized,CE Marked,RoHS Compliant Yes |
| Sub Brand | Bussmann Series Yes |
| Type | High speed cylindrical fuse Yes |
| Product Image |
|
|
|
|
|---|---|---|---|---|
|
KAW-30
Eaton Bussmann series KAW semiconductor fuse, 30 A
$126.57 / EA
|
FWC-25A10F
Eaton Bussmann series FWC high speed cylindrical fuse, 500 Vac/dc (35-800A only), 25A, 200 kAIC Vac, 50 kAIC at 700 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end
$27.03 / EA
|
FWC-32A10F
Eaton Bussmann series FWC high speed cylindrical fuse, 600V (UL), 32A, 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end, Class aR, White, Ceramic
$27.03 / EA
|
||
| Attributed Data | ||||
| Amperage Rating | 25 A 25 A | 30 A 30 A | 32 A 32 A | |
| Class | Class aR Class aR | |||
| Connection | Ferrule end x ferrule end Ferrule end x ferrule end | |||
| Dimensions | 0.3600 IN X 0.3600 IN X 1.5000 IN 0.3600 IN X 0.3600 IN X 1.5000 IN | 1.4961 IN X 0.4331 IN X 0.4331 IN 1.4961 IN X 0.4331 IN X 0.4331 IN | ||
| Interrupt Rating | 50 kAIC at 300 Vdc200 kAIC at 300 Vdc 50 kAIC at 300 Vdc200 kAIC at 300 Vdc | 50 kAIC at 700 Vdc200 kAIC Vac 50 kAIC at 700 Vdc200 kAIC Vac | ||
| Material | Ceramic Ceramic | |||
| Size | 0.406 In Diameter X 1.500 In Length 0.406 In Diameter X 1.500 In Length | |||
| Standard | CSA Certified ,UL Recognized,CE Marked,RoHS Compliant CSA Certified ,UL Recognized,CE Marked,RoHS Compliant | CSA Certified,UL Recognized,CE Marked,RoHS Compliant CSA Certified,UL Recognized,CE Marked,RoHS Compliant | Contact factory,Contact Manufacturer Contact factory,Contact Manufacturer | UL Recognized ,CSA Certified,CE Marked UL Recognized ,CSA Certified,CE Marked |
| Sub Brand | Bussmann Series Bussmann Series | |||
| Type | High speed cylindrical fuse High speed cylindrical fuse | Semiconductor fuse Semiconductor fuse | ||
| Voltage Rating | 600 V 600 V | |||
